32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
Specifications
Screen Tilt Angle :
30° (±15°)
Package Dimensions :
795*670*200MM
Charging Voltage :
9-20V
Multimedia :
4K@30fps (H.264, HEVC,VP8)
Screen Lift Travel :
180MM
Resolution :
1920*1080
OS :
Android14
Screen Rotation Angle :
90 degrees clockwise
Net Weight :
18.5KG
Battery Capacity :
7800mAH
RAM :
4G/8G
Touchscreen :
Capacitive Touch/INCELL
Output Voltage :
14.8V
Brand Name :
MTHGH
Model Number :
XYC-32
Certification :
CE FCC ROHS ISO14001 ISO45001 ISO9001
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
Alipay,L/C,T/T
Supply Ability :
10000 Piece
Delivery Time :
7-10 Work Days
Packaging Details :
Standard carton package : carton+ plastic bag+ foam+ honeycomb paperboard+ pack thread.
Total Battery Power :
114w/h
Maximum Tilt Angle :
18°
ROM :
64G/128G
Product Size :
32 Inch
Gross Weight :
21KG
Description

32 Inch Stand By Me Smart TV 4K 30fps 300cd RAM 8G ROM 128G

A unique mobile display product that combines the characteristics of commercial tablets and displays with the advantages of portability, mobility, and compact size. Built on an advanced open Android platform.

4K@30fps Support
60Hz Refresh Rate
300cd Brightness
7800mAh Battery
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support

Available Screen Size Matrix

Scalable dimensions to suit retail, corporate, and hospitality environments. Sized precisely for user ergonomics.

27"
Model: LY-H1270

32"
Model: LY-H1320

Intelligent Deployment & Integration

Whether deployed in living rooms, bedrooms, kitchens, balconies, or outdoor commercial spaces, this mobile TV seamlessly integrates into any environment. The Android platform provides excellent app compatibility and direct integration into a broader ecosystem.

32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
1

Seamless App Compatibility

Operates on a powerful Android architecture with 8G RAM and 128G ROM, allowing seamless downloads and high-speed operation for digital signage or entertainment apps.

2

High-Performance Display

A fluid 60Hz refresh rate combined with 300cd brightness ensures crystal clear visibility for fitness applications, presentations, short videos, and commercial karaoke scenarios.

Precision Ergonomics & Hardware

90°

Screen Rotation

Smooth 90-degree clockwise rotation toggling instantly between landscape and portrait formats.

180mm

Vertical Lift

180MM screen lifting travel adjusting perfectly to viewing height whether standing or seated.

30°

Tilt Adjustment

30° (±15°) tilt angle capability with a maximum 18° forward tilt, optimizing viewing for all lighting environments.

Function Introduction & Architecture

32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support 32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support

Hardware Assembly & Deployment Guide

Follow these strict factory-standard steps to ensure secure assembly and optimal performance of your Stand By Me TV display chassis and lift mechanics.

Step 01: Unboxing Verification
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
After opening the outer box packaging, take out the manual and other accessories. Check whether the relevant accessories are complete, and read the manual carefully.
Step 02: Tool Extraction
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
Locate and take out the necessary installation tools directly from the chassis tool box provided with the unit.
Step 03: Bracket Assembly
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
Open the folding bracket and tighten the fixed hexagon socket screw securely using the provided wrench.
Step 04: Chassis Attachment
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
Carefully align and install the tightened bracket directly onto the weighted bottom chassis.
Step 05: Turntable Mounting
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
Place the turntable into the display mounting position and tighten the screws with a medium-sized wrench.
Step 06: Mechanics Test
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
Check whether the installation position is tight and whether the moving, lifting, and rotating mechanisms operate smoothly without resistance.
Step 07: Power Activation
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
Turn on the internal battery power switch located at the base, turn on the one-touch start button, and initiate system boot.
Step 08: Final QA Verification
32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support
Check whether the charging and discharging metrics are normal, the INCELL touch screen is responsive, and the sound output is clear.

B2B OEM / Factory Procurement

As a factory-direct source for bulk wholesale procurement, we provide streamlined export processes for smart mobile displays.

1
Requirement
Confirm Size/RAM
2
Production
Assembly & OS Load
3
QC Testing
Touch/Battery Check
4
Packaging
Secure Export Boxing
5
Deployment
Commercial Launch

Export Packaging Standard

32 Inch Stand By Me Smart TV with Android14 OS and 4K@30fps Multimedia Support

Each unit is securely packed within robust internal bubble padding and an outer carton measuring 795*670*200MM, with a gross weight of 21KG ensuring maximum freight safety for international export and wholesale distribution.

Factory-Direct Technical Specifications

Specifications Model: LY-H1320 Model: LY-H1270
Display 32" Diagonal 27" Diagonal
Resolution 1920*1080 FHD 1920*1080 FHD
Brightness 300cd 300cd
Operating System Android Android
Memory (RAM) 4G / 8G 4G / 8G
Storage (ROM) 64G / 128G 64G / 128G
Multimedia Support 4K@30fps (H.264, HEVC, VP8) 4K@30fps (H.264, HEVC, VP8)
Touchscreen Capacitive Touch / INCELL Capacitive Touch / INCELL
Remote Control Bluetooth / Infrared Bluetooth / Infrared
Battery Capacity 7800mAH 7800mAH
Output Voltage 14.8V 14.8V
Charging Voltage 9-20V 9-20V
Total Battery Power 114w/h 114w/h
Screen Rotation Angle 90 degrees clockwise 90 degrees clockwise
Screen Lift Travel 180MM 180MM
Screen Tilt Angle 30° (±15°) 30° (±15°)
Maximum Tilt Angle 18° 18°
Net Weight 18.5KG 18.5KG
Gross Weight 21KG 21KG
Package Dimensions 795*670*200MM 795*670*200MM

Procurement FAQ

Can this device decode 4K content?

Yes. While the screen resolution is explicitly 1920*1080 (FHD), the internal hardware natively decodes and supports 4K@30fps multimedia playback (H.264, HEVC, VP8).

What is the total power capability of the internal battery?

The integrated battery has a capacity of 7800mAH, delivering a total battery power of 114w/h with a 14.8V output voltage, perfectly supporting mobile presentations and deployment.

Is the touchscreen hardware included on all models?

Yes, both the 27" and 32" models feature advanced Capacitive Touch / INCELL hardware interfaces.
