4.0V 220mAh Sealed Lithium Supercapacitor Cell LSC1550 for Energy Storage
4.0V 220mAh Sealed Lithium Supercapacitor Cell LSC1550 for Energy Storage
Specifications
Nominal Capacity(3.67V) :
220mAh
Nominal Voltage :
4.0Volt
Product System :
Lithium Supercapacitor Cell
Operating Temperature :
﹣40℃～+85℃
Applications :
Remote/Wireless, Intelligent Fire Control System
Weight :
About 21g
Model Number :
LSC1550
Certification :
CE, ROHS, UN38.3
Place of Origin :
Wuhan
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T
Supply Ability :
10000PCS/30Days
Delivery Time :
20 Days
Packaging Details :
Carton
Internal Resistance :
≤150mΩ
Description
4.0V 220mAh Sealed Lithium Supercapacitor Cell Energy Storage
Product Overview

The Lithium supercapacitor is a composite energy storage device fabricated by hybrid lithium ion secondary batteries electrode materials, including graphite, lithium cobalt oxide, lithium iron phosphate, and metal oxides, with an activated porous carbon with high specific surface area. Due to the addition of lithium-ion batteries electrode materials, the energy storage mechanism of the composite supercapacitors is no longer the traditional non-faradic double-layer charge storage mechanism.

Performance Specifications
Product System Lithium Supercapacitor Cell
Model LSC1550
Nominal Capacity (4.0V) 220mAh
Nominal Voltage 4.0V
Internal Resistance ≤150mΩ
Max. Continuous Discharge Current 2000mA
Max. Pulse Current 5000mA
Max. Charge Current 1000mA
Max. Charge Voltage 4.0V
Discharge End Voltage 2.5V
Operating Temperature ﹣40℃～+85℃
Weight About 21g
Characteristic Curves
4.0V 220mAh Sealed Lithium Supercapacitor Cell LSC1550 for Energy Storage 4.0V 220mAh Sealed Lithium Supercapacitor Cell LSC1550 for Energy Storage 4.0V 220mAh Sealed Lithium Supercapacitor Cell LSC1550 for Energy Storage
Discharge Curve at 25℃
4.0V 220mAh Sealed Lithium Supercapacitor Cell LSC1550 for Energy Storage
Key Advantages
  • Instantaneous large current discharge capability
  • Long-life energy storage device
  • Fully sealed structure and wide working temperature range
  • Suitable for long-term use in harsh environments
Download Technical Datasheet (PDF)
