Fully Sealed LSC1520 Lithium Supercapacitor Cell with 180AS Nominal Capacity and Wide Operating Temperature Range
Fully Sealed LSC1520 Lithium Supercapacitor Cell with 180AS Nominal Capacity and Wide Operating Temperature Range
Specifications
Weight :
About 10g
Nominal Capacity(3.67V) :
180AS
Operating Temperature :
﹣40℃～+85℃
Applications :
Intelligent and Instrument Area, Remote/Wireless, Intelligent Fire Control System
Model Number :
LSC1520
Certification :
CE, ROHS, UN38.3
Place of Origin :
Wuhan
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T
Supply Ability :
10000PCS/30Days
Delivery Time :
20 Days
Packaging Details :
Carton
Nominal Voltage :
3.67V
Product System :
Lithium Super-Capacitor Cell
Internal Resistance :
≤150mΩ
Description
Fully Sealed Wireless LSC1520 Lithium Supercapacitor Cell
Product Overview

The LSC1520 Remote/Wireless Lithium Supercapacitor Cell features a fully sealed structure designed for reliable performance in demanding applications.

Product Features

The Lithium supercapacitor is a composite super-capacitor fabricated by hybrid lithium ion secondary batteries electrode materials, including graphite, lithium cobalt oxide, lithium iron phosphate, and metal oxides, with an activated porous carbon with high specific surface area.

Due to the addition of lithium-ion batteries electrode materials, the energy storage mechanism of the composite super-capacitors demonstrates higher energy density than traditional double-layer capacitors and higher power density than rechargeable batteries, while ensuring high energy, high power, and long cycle life.

Performance Data
Product System Lithium Super-Capacitor Cell
Model LSC1520
Nominal Capacity (3.67V) 180AS
Nominal Voltage 3.67V
Internal Resistance ≤150mΩ
Max. Continuous Discharge Current 600mA
Max. Pulse Current 2000mA
Max. Charge Current 300mA
Max. Charge Voltage 4.0V
Discharge End Voltage 2.5V
Operating Temperature ﹣40℃～+85℃
Weight About 11g
Characteristic Curves
Fully Sealed LSC1520 Lithium Supercapacitor Cell with 180AS Nominal Capacity and Wide Operating Temperature Range
Fully Sealed LSC1520 Lithium Supercapacitor Cell with 180AS Nominal Capacity and Wide Operating Temperature Range
Fully Sealed LSC1520 Lithium Supercapacitor Cell with 180AS Nominal Capacity and Wide Operating Temperature Range
Discharge Curve at 25℃
Fully Sealed LSC1520 Lithium Supercapacitor Cell with 180AS Nominal Capacity and Wide Operating Temperature Range
Key Advantages
  • Instantaneous large current discharge capability
  • Long-life energy storage device
  • Fully sealed structure and wide working temperature range
  • Suitable for long-term use in harsh environments
