0.5t To 30t Weighing Module Stainless Steel Weighing Scale Module
0.5t To 30t Weighing Module Stainless Steel Weighing Scale Module
0.5t To 30t Weighing Module Stainless Steel Weighing Scale Module
0.5t To 30t Weighing Module Stainless Steel Weighing Scale Module
0.5t To 30t Weighing Module Stainless Steel Weighing Scale Module
0.5t To 30t Weighing Module Stainless Steel Weighing Scale Module
0.5t To 30t Weighing Module Stainless Steel Weighing Scale Module
0.5t To 30t Weighing Module Stainless Steel Weighing Scale Module
Specifications
Operating Temperature :
-40℃～+80℃
Protection Level :
IP68
Product :
Weighing Module
Anti Eccentric Load Capacity :
≤ 150% rated load
Range :
0.5t～30t
Place of Origin :
China
Packaging Details :
carton packaging
Delivery Time :
20 days
Payment Terms :
Payment before delivery
Supply Ability :
1,000 units per month
Brand Name :
Linmindu
Model Number :
LMD-BWGM
Material :
Alloy steel/stainless steel
Description

High stability LMD-BWGM weighing module with strong anti-interference, suitable for silo weighing, tank weighing and automatic batching systems in various industrial fields.

The LMD-BWGM corrugated tube static load weighing module has a compact and simple structure that does not require the installation of other accessories. It has two working modes: anti overload, anti fatigue, anti eccentric load, and can withstand tension and compression. The sensor pressure head with automatic centering function enables accurate measurement, good repeatability, fast and simple installation, saving installation and maintenance time. The weighing module structure is equipped with horizontal limit and lifting structure, which can quickly and conveniently install, maintain and replace sensors.

Product Features

  • The sensor is welded and sealed with stainless steel/alloy steel material, with a protection level of IP68, and can be used in various harsh environments
  • Spherical connector, always maintaining the vertical weighing state of the module
  • Support bolts to prevent equipment from overturning
  • Easy and fast installation
  • Easy maintenance, saving downtime for maintenance
  • Suitable for ingredient weighing control of small and medium-sized weighing reactors in industries such as chemical, pharmaceutical, and food
  • Explosion proof mark: EX IA IIC T4-T6 GA, EX IA D20 T85-T135

Specifications

Project

Parameters

Material

Alloy steel/stainless steel

Range

0.5t～30t

Precision

OIML C3/0.02%FS

Protection Level

IP68

Output

2.0±0.1mV/V

Operating Temperature

-40℃～+80℃

Installation Method

Shear bolt fixation, modular installation

Safe Load

150% FS (limit)

Anti Eccentric Load Capacity

≤ 150% Rated load
