High Temp Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C
High Temp Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C
High Temp Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C
High Temp Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C
High Temp Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C
High Temp Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C
High Temp Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C
High Temp Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C
Specifications
Brand Name :
SUNWOOL
Model Number :
1260STD HP 1430
Certification :
ISO CE SGS
Place of Origin :
CHINA
MOQ :
10 rolls
Price :
6.0usd - 10.0usd Price
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
3000 Rolls/Day
Delivery Time :
10 days
Packaging Details :
Woven Bag or Carton Box
Application :
Furnace lining, kiln insulation, thermal insulation
Density :
96kg 128kg 160kg
Refractoriness :
1050-1800C
Size :
Customizable
Package :
bag or carton box or pallet
Shape :
Customizable
Color :
White
Type :
blanket board module paper textile
Description
High Temperature Ceramic Fiber Blanket For Furnace Thermal Insulation 1260°C 1430°C

Leadsun ceramic fiber blanket is manufactured from long, flexible, interwoven ceramic fibers produced through advanced blown and spun processes. This structure creates a strong, lightweight, and highly durable insulation blanket, designed for high-temperature applications ranging from 1100°C to 1430°C.

Compared with traditional hard refractory materials, ceramic fiber blanket offers excellent heat resistance while delivering up to five times higher thermal insulation efficiency, significantly reducing heat loss and improving energy efficiency in industrial furnaces and thermal equipment.

Technical Index
Types(°C) 1050 Common 1260 STD 1260 HP 1400 1430 HZ
Operation Temp(°C)

950°C

(1742 °F )

1050°C

(1922°F)

1100°C

(2012°F)

1200°C

(2192°F)

1350°C

(2462°F)

Density

(kg/m3)

64 - 96 - 128 - 160
Permanent Change on Heating (%)

950°Cx24h

≤-3

1050°Cx24h

≤-3

1100°Cx24h

≤-3

1200°Cx24h

≤-3

1350°Cx24h

≤-3

Theoretic Heat Conductive Co-efficient W/(m·k)(128kg/m3)

0.15

(600°C)

0.22

(800°C)

0.12

(600°C)

0.20(

800°C)

0.12

(600°C)

0.20

(800°C)

0.12

(600°C)

0.20

(800°C)

0.16

(800°C)

0.20

(1000°C)

Tensile Strength

(Thickness 25mm)

≥0.04

≥0.05

≥0.05

≥0.04

≥0.06

Chemical

Composition

 Al2O3(%)

44

45-46

47-49

52-55

39-40
Al2O3+SiO2(%)

≥96

≥98

≥99

≥99

-
ZrO2(%)

-

-

-

-

15-17

Al2O3+SiO2

+ZrO2(%)

-

-

-

-

≥99
Fe2O3(%)

≤1.0

≤0.8

≤0.2

≤0.2

≤0.2
Na2O+K2O(%)

≤0.4

≤0.3

≤0.2

≤0.2

≤0.2
CaO+MgO

≤0.3

≤0.2

≤0.2

≤0.2

≤0.
Features

  • Low thermal conductivity, ensuring excellent thermal insulation and reduced heat loss

  • Very low heat storage, allowing faster heating and cooling cycles

  • High tensile strength, providing durability and long service life

  • Excellent resistance to thermal shock, maintaining performance under rapid temperature changes

  • Good sound absorption properties, contributing to noise reduction

  • Quick and easy repairs — in the event of lining damage, the furnace can be cooled rapidly to minimize downtime

  • Binder-free composition, producing no fumes and causing no contamination to the furnace atmosphere

Applications
Ceramic Industry

  • Kiln car insulation and sealing

  • Thermal insulation for continuous and batch kilns

Steel Industry

  • Heat treatment and annealing furnace insulation

  • Furnace door linings and high-temperature seals

  • Soaking pit covers and sealing systems

  • Furnace hot-face insulation and repair applications

  • Reheating furnace insulation and ladle cover insulation

Refining & Petrochemical Industry

    • Reformer and pyrolysis furnace linings

    • Tube seals, gaskets, and expansion joints

    • High-temperature insulation for pipes, ducts, and turbines
