Specifications
Brand Name :
SUNWOOL
Model Number :
Ceramic Fiber Blanket
Certification :
ISO CE
Place of Origin :
China
MOQ :
10roll
Price :
5.5-9.9usd/roll
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
10000rolls/month
Delivery Time :
10days
Packaging Details :
woven bag/carton
Refractoriness :
1050-1800C
Size :
Customizable
Package :
bag or carton box or pallet
Shape :
Customizable
Color :
White
Type :
blanket board module paper textile
Description
Ceramic Fiber Blanket – Flexible, High-Temperature Insulation for Demanding Industrial Applications
Product Overview:

Our Ceramic Fiber Blanket is composed of long, flexible, interwoven fibers manufactured by the “blown” and “spun” process. It yields a strong, lightweight, and durable blanket designed for continuous service in a temperature range from 1100°C to 1430°C, depending on the grade. It combines the heat resistance of a hard refractory with a thermal insulation value five times better, making it an ideal solution for energy saving and thermal management.

Technical Index
Description STD Blanket High Pure Blanket High zirconium Blanket
AL2O3(％) ≥44 ≥45 ≥34
AL2O3+SiO2 (%) ≥96 ≥99 ≥84
Fe2O3+TiO2(%) ≤1.0 ≤0.5 ≤0.5
ZrO2 (%) - - ≥15
K2O+Na2O(％) ≤1.0 ≤0.2 ≤0.2
Density (kg/m3) 64 96 128 96 128 128 160
Classification Temperature
(℃)		 1260 1260 1430
Fiber Diameter(um) 3.5 3.5 3.5
Shot Content(%) ≤15 ≤15 ≤15
Shrinkage after Heating (%) 1000C *24h≤2.5 1100C *24h≤2.5 1350C *24h≤3.5
Thermal Conductivity(W/m·k)
400℃ 0.090 0.095 0.124 0.114 0.101 0.138 0.122 0.118
500℃ 0.119 0.123 0.145 0.135 0.120 0.179 0.153 0.149
600℃ 0.152 0.158 0.202 0.191 0.175 0.233 0.184 0.172
Tensile Strength(Mpa) 0.040 0.05 0.05 0.060 0.075 0.050 0.060 0.075
Key Features:
  • Low Thermal Conductivity: Excellent insulation properties reduce heat loss.
  • Very Low Heat Storage: Enables rapid heating and cooling cycles.
  • High Tensile Strength: Durable and resistant to tearing during handling and installation.
  • Excellent Thermal Shock Resistance: Performs reliably under rapid temperature changes.
  • No Binder, Safe: Contains no binders, producing no fumes or furnace atmosphere contamination. It is asbestos-free.
  • Quick Installation & Repair: Requires no curing or dry-out time; can be fired to operating temperature immediately. Damaged linings can be cooled and repaired quickly.
Applications:
  • Ceramic Industry: Kiln car insulation and seals, continuous and batch kilns.
  • Steel Industry: Heat treating/annealing furnaces, furnace door linings, soaking pit covers, ladle covers, hot face repairs.
  • Refining & Petrochemical: Reformer and pyrolysis lining, tube seals/gaskets, high-temperature pipe/duct insulation.
  • General: Back-up insulation, expansion joints, and areas requiring sound absorption.
