Specifications
Brand Name :
LEADSUN
Model Number :
1000C 1100C
Certification :
ISO CE
Place of Origin :
CHINA
MOQ :
10 pcs
Price :
2.0usd - 15.0usd
Payment Terms :
L/C,T/T,D/P,Western Union
Supply Ability :
2000 m3/month
Delivery Time :
10 days
Packaging Details :
Carton box + Pallet
Refractoriness :
1000-1100C
Size :
customizable
Package :
carton box + pallet
Type :
board,pipe
Color :
White
Density :
240-800kg/m3
Description
High Temperature Calcium Silicate Insulation Board for Industrial Furnaces

Leadsun Calcium Silicate Board is an asbestos-free thermal insulation material designed for continuous service temperatures from 650°C to 1100°C. It is lightweight, durable, and offers low thermal conductivity and high mechanical strength. Available in 650, 1000, and 1100 grades, it is widely used as backup insulation in steel, petrochemical, ceramic, cement, and glass industries, and for fire protection in construction. It helps improve energy efficiency, production performance, and workplace safety. In building applications, it is also suitable for ceilings, fireproof walls, and decorative sound-absorbing panels.

Physical index Unit L-200 L-230 L-250 L-270
Density kg/m3 200±10% 230±10% 250±10% 270±10%
Cold Crushing Strength Mpa ≥0.60 ≥0.80 ≥0.90 ≥1.00
Flexural Strength Mpa ≥0.35 ≥0.45 ≥0.50 ≥0.55
Maximum Service Temp. ℃ 1000℃ 1000℃ 1000℃ 1000℃
Linear Shrinkage(1000℃x16hrs) % ≤2 ≤2 ≤2 ≤2
Thermal Conductive w/(m.k) 200℃ 0.075

400℃ 0.098

600℃ 0.150

800℃ 0.210		 200℃ 0.085

400℃ 0.100

600℃ 0.152

800℃ 0.214		 200℃ 0.095

400℃ 0.108

600℃ 0.156

800℃ 0.216		 200℃ 0.098

400℃ 0.110

600℃ 0.158

800℃ 0.218
Compression Strength at 10% Deformation after 16hrs*1000℃ Mpa 0.32 0.40 0.45 0.50
Porosity % 90.80 90.60 90.40 90.00
Moisture Content % 3-5%
PH Value % 8-9%
Color / white
Surface Condition / 1.Original dimple pattern.
2.Double sanded, smooth and good flatness.
Features

  • High temperature resistance up to 1100°C

  • Asbestos-free and environmentally safe

  • Low thermal conductivity for excellent insulation

  • High mechanical strength with good flexural and compressive performance

  • Lightweight and easy to handle for fast installation

  • Moisture resistant, stable in wet conditions

  • Excellent dimensional stability under thermal cycling

  • Suitable for both industrial and construction applications

Applications

  • Furnace backup insulation (reheating, annealing, rotary kilns)

  • Steel & metallurgy (ladles, tundishes, hot metal cars)

  • Petrochemical (heaters, reformers, pipe supports)

  • Ceramic & cement (tunnel kilns, nozzles, flow gates)

  • Building construction (fireproof ceilings, wall insulation)

  • Power & HVAC (boilers, duct lining)

Standard Sizes:
  • Thickness: 25mm, 50mm, 75mm, 100mm (custom thickness available)
  • Dimensions: 1200mm × 600mm, 1200mm × 1200mm, or as customized
