Customizable Rockwool Insulation Sheets Fireproof Acoustic Insulation For Thermal Building
Customizable Rockwool Insulation Sheets Fireproof Acoustic Insulation For Thermal Building
Customizable Rockwool Insulation Sheets Fireproof Acoustic Insulation For Thermal Building
Customizable Rockwool Insulation Sheets Fireproof Acoustic Insulation For Thermal Building
Customizable Rockwool Insulation Sheets Fireproof Acoustic Insulation For Thermal Building
Customizable Rockwool Insulation Sheets Fireproof Acoustic Insulation For Thermal Building
Specifications
Brand Name :
LEADSUN
Model Number :
SUNWOOL
Certification :
ISO CE
Place of Origin :
40-200KG/M3
MOQ :
100 psc
Price :
1.0usd - 5.0usd
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
1000 tons/month
Delivery Time :
7 days
Packaging Details :
Plastic Bag
Refractoriness :
750C
Size :
customizable
Package :
plastic bag
Type :
board,pipe blanket
Blanket density :
50-120kg/m3
Board density: :
40-200kg/m3
Pipe density :
80-150kg/m3
Description
Rockwool Insulation For Thermal Building And Acoustic Insulation

Rock wool products are made from high-quality melted basalt using an advanced four-roller centrifugal process, forming non-continuous fibers with a diameter of 4–7 μm. During production, binders, dust-suppression oil, and water-repellent agents are added, followed by curing and cutting. The products are available in different densities and forms, including blankets, boards, and pipe sections, with optional wire mesh facing. Rock wool is widely used for thermal insulation in construction, petroleum, electric power, and chemical industries, as well as for building partition walls, curtain walls, roofs, and building envelope insulation.

Technic parameter
Product performance Unit LDS 60-200 Standard
Apparent Density kg/m3 140 160 180 GB/T5480
Compression strength(10%defomation) kPa ≥40 ≥50 ≥60 GB/T13480
Tensile strength (perpendicular to surface) kPa ≥7.5 ≥10 ≥15 JG149-2003
Thermal conductivity(25℃) w/(m•K) ≤0.040 ≤0.040 ≤0.040 GB/T10295
Fire resistant -- Non-combustible grade A GB/T8624
Water repellence % ≥98 ≥98 ≥98 GB/T10299
Acid index -- ≥1.8 ≥1.8 ≥1.8 GB/T5480
Moisture absorption % ≤1.0 ≤1.0 ≤1.0 GB/T5480
water Absorption(partial immersion 24h) kg/m2 ≤0.5 ≤0.5 ≤0.5 GB/T25975-2010
water Absorption(partial immersion 28d) kg/m2 ≤2.0 ≤2.0 ≤2.0 GB/T25975-2010
Noise Reduction Coefficient(NRC) --- ≥0.6 ≥0.6 ≥0.6 GB/T18696
Dimension Stability % ≤1.0 ≤1.0 ≤1.0 GB/T8811
Thickness Tolerance mm ±3 ±3 ±3 GB/T5480
Squareness mm/m ≤5 ≤5 ≤5 GB/T5480
Flatness mm ≤6 ≤6 ≤6 GB/T25975-2010
Melting Point ℃ ＞1000
Typical Applications
  1. Specially designed for external thermal insulation composite systems (ETICS).
  2. Suitable for insulation systems of dry-hung stone curtain walls, aluminum-plastic composite panel curtain walls, and aluminum panel curtain walls.
  3. Used as a fire barrier in external thermal insulation systems with non-Class A fire-rated insulation materials.
  4. Applicable to areas with high requirements for fire resistance, thermal insulation, and water resistance.
