High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings
High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings
High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings
High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings
High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings
High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings
Specifications
Packaging Details :
woven bag
MOQ :
1pcs
Price :
Negotiable
Certification :
ISO CE
Place of Origin :
China
Delivery Time :
10-15days
Brand Name :
Leadsun
Payment Terms :
L/C,D/P,T/T,Western Union
Model Number :
LR140, LR160, LR180
Description

High Quality Factory Sale Insulating Rock Wool Board

Rock Wool Board is a high-performance, inorganic insulation material manufactured from natural volcanic rock, typically basalt or diabase, and recycled slag. The raw materials are melted at extreme temperatures (approximately 1,500°C) and then spun into fine fibers using a centrifugal process. These fibers are then bonded with a thermosetting resin and formed into rigid or semi-rigid boards.
External thermal insulation rock wool board is specially designed for external thermal insulation composite system.It has the quality of high tensile strength, good dimensional stability, water repellent, low water absorption etc. We have three different products to meet customer's needs i.e. LR140, LR160, LR180.

Technical Specifications

Product performance

Unit

LDS 60-200

Standard

Apparent Density

kg/m3

140

160

180

GB/T5480

Compression strength(10%defomation)

kPa

≥40

≥50

≥60

GB/T13480

Tensile strength (perpendicular to surface)

kPa

≥7.5

≥10

≥15

JG149-2003

Thermal conductivity(25℃)

w/(m•K)

≤0.040

≤0.040

≤0.040

GB/T10295

Fire resistant

--

Non-combustible grade A

GB/T8624

Water repellence

%

≥98

≥98

≥98

GB/T10299

Acid index

--

≥1.8

≥1.8

≥1.8

GB/T5480

Moisture absorption

%

≤1.0

≤1.0

≤1.0

GB/T5480

water Absorption(partial immersion 24h)

kg/m2

≤0.5

≤0.5

≤0.5

GB/T25975-2010

water Absorption(partial immersion 28d)

kg/m2

≤2.0

≤2.0

≤2.0

GB/T25975-2010

Noise Reduction Coefficient(NRC)

---

≥0.6

≥0.6

≥0.6

GB/T18696

Dimension Stability

%

≤1.0

≤1.0

≤1.0

GB/T8811

Thickness Tolerance

mm

±3

±3

±3

GB/T5480

Squareness

mm/m

≤5

≤5

≤5

GB/T5480

Flatness

mm

≤6

≤6

≤6

GB/T25975-2010

Melting Point

℃

＞1000


Why Choose Our Products?

  • Excellent Thermal Insulation:Low thermal conductivity (typically 0.035-0.045 W/m·K) helps reduce energy consumption in buildings and industrial applications.
  • Superior Fire Resistance:Rock wool is non-combustible (Class A1 or A2 according to European standards). It can withstand temperatures up to 1,000°C without melting, acting as an effective fire barrier.
  • Acoustic Performance:The fibrous structure provides excellent sound absorption, making it ideal for noise reduction in walls, ceilings, and floors.

Primary Applications

  • This product is specially designed for external thermal insulation composite system.
  • Suitable for dry hanging stone curtain wall, aluminum-plastic composite plate curtain wall, aluminum panel curtain wall insulation system etc.
  • Used as fire barrier for external thermal insulation composite system of non-class A fire classification insulation.
  • Other places that has high requirement for fire-proof, thermal insulation, water-proof etc.


High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings

High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings

High Performance Rock Wool Board Thermal Insulation Fire Resistance Acoustic Performance For Energy Efficient Buildings


Frequently Asked Questions (FAQ)

Q1: Do rock wool boards contain hazardous substances like formaldehyde or crystalline silica?

A: Our standard rock wool boards are formaldehyde-free and comply with international health standards, such as the EU CE mark and US EPA regulations. Although trace amounts of crystalline silica may be naturally present, our products meet OEQ Class I (Ecological Quality Class) standards and are classified as non-carcinogenic under EU Regulation (EC) No. 1272/2008.

Q2: What is the maximum service temperature of your rock wool boards?

A: Our standard boards have a continuous operating temperature range of 750°C (1382°F) to 1000°C (1832°F); depending on density (e.g., 120–200 kg/m³), they can withstand short-term peak temperatures of up to 1200°C (2192°F). For higher temperature requirements, please inquire about our ceramic fiber alternatives.

Q3: What densities are available for your rock wool boards?

A: Typical densities range from 60 kg/m³ (lightweight, for sound or thermal insulation backing layers) to 200 kg/m³ (high-strength, for furnace walls subject to mechanical loads). Higher density offers superior erosion resistance but relatively lower thermal shock resistance. We can provide recommendations based on your specific application.
