Six Servos Glass Production Line , Film Glass Edge Deletion Two Way Access
Six Servos Glass Production Line , Film Glass Edge Deletion Two Way Access
Specifications
Brand Name :
LIJIANG GLASS
Model Number :
LJCM2545
Certification :
CE
Place of Origin :
JINAN.CHINA
MOQ :
One set
Price :
Negotiable
Supply Ability :
100 sets per year
Delivery Time :
35 days
Packaging Details :
Container
Production name :
Low-e glass deletion machine
Max.glass processing size :
2500*4500mm
Min.glass processing size :
350*500mm
Glass thickness :
3-19mm
Edge deleting width :
10-50mm
Glass conveyor speed: :
30m/min
Abrasive wheel width :
10/12/15mm
Description

Six Servos Glass Production Line 30 M/Min , Film Glass Edge Deletion Two Way Access

Automatic low-e glass edge deletion machine adopts Germany siemens brand spare parts, cooperating with Bystronic technology to develop the smart machine.

Technical data

Max.glass processing size 2500*4500mm
Min.glass processing size 350*500mm
Glass thickness 3-19mm
Edge deleting width 10-50mm
Glass conveyor speed: 30m/min
Edge deleting speed 0-15m/min
Abrasive wheel width 10/12/15mm
Air supply Flow 0.2m3/min
Air pressure ≥0.8MPa
Total power 3P 380V 50Hz 3.35KW
Dimension 8000*2500*3400mm

Main feature

  • PLC control system,touch screen interface
  • Six servos control system
  • Intelligent control system, can recognize batch processing
  • Two-way glass access
  • Automatically measure size
  • Automatically distinguish low-e surface
  • Edge deletion is adjustable
  • Safe and full automatic device

Introduce :

1. Application : Insulated glass processing machine

2. Production name : Smart vertical glass edge deletion machine

3. Max glass size: 2500*4500mm

4. Min glass size : 400*400mm

5. Edge deleting speed : 2-29m/min

6. Total power : 3P 380V 50Hz 3.35KW

7. Glass thickness : 3 - 15mm

8. Place of origin : Jinan city, China

9. Brand name : LIJIANG GLASS

10. Using : Deleting low-e glass edge
Six Servos Glass Production Line , Film Glass Edge Deletion Two Way Access
