Liquid Silicone Rubber Ski Goggle Vent Plug Molding Machine Vent Plug LSR High-Precision Injection Molding Machine
Liquid Silicone Rubber Ski Goggle Vent Plug Molding Machine Vent Plug LSR High-Precision Injection Molding Machine
Liquid Silicone Rubber Ski Goggle Vent Plug Molding Machine Vent Plug LSR High-Precision Injection Molding Machine
Liquid Silicone Rubber Ski Goggle Vent Plug Molding Machine Vent Plug LSR High-Precision Injection Molding Machine
Liquid Silicone Rubber Ski Goggle Vent Plug Molding Machine Vent Plug LSR High-Precision Injection Molding Machine
Liquid Silicone Rubber Ski Goggle Vent Plug Molding Machine Vent Plug LSR High-Precision Injection Molding Machine
Specifications
Brand Name :
Better
Model Number :
Better 1600SD
Certification :
CE、ISO
Place of Origin :
China
MOQ :
1 SET
Price :
USD42000-USD82000per set
Payment Terms :
T/T
Supply Ability :
15 sets per month
Delivery Time :
45 days
Packaging Details :
Plastic film
Warranty :
1 year
Style :
Vertical
Operation :
Easy operation
Motor :
Servo Motor
Description
Liquid Silicone Rubber Ski Goggle Vent Plug Molding Machine
BETTER Vertical LSR injection molding machine designed for high-precision manufacturing of vent plugs and other silicone components.
Technical Specifications
Clamping Force160 tons
Size1500 × 730 mm
Max Mold Size720 × 660 mm
Min Mold Height300 + 50 mm
Mold Stroke300 mm
Max Daylight600 + 50 mm
Ejector Force4 tons
Thimble DiameterΦ30
Ejector Distance (Product)130 (100) mm
Max Hydraulic Pressure140 kg/cm²
Cooling Water1500-1800 liters/hr
Heater Power4 kW
Motor Power22 kW
Dimension (L×W×H)2.86 × 2.76 × 3.30 m
Weight9.6 tons
Machine Overview
Liquid Vertical Injection Molding Machine with Double Sliding Board. BETTER LSR Injection Molding Machine is manufactured with CE and ISO certified production controller. This Vertical Double Slides Table LSR Injection Molding Machine is widely used for medical silicone products, electronic silicone seals, and precision components.
Key Features
  • Direct pressure mould opening and closing system with horizontal injection structure for faster mold adjustment and precise position control
  • Advanced sliding rail structure reduces oil pollution and ensures faster, steadier operation
  • Active pin valve-pattern nozzle sealing system guarantees accurate injection
  • Supports multi-station production requirements
  • High-performance servo motor system for precise operation and energy efficiency
  • Ideal for automated removal of LSR parts from the mold
LSR Injection Molding Industry Applications
Maternal and Baby Industry
Non-polluting liquid silicone materials are widely used for silicone products including nipples, pacifiers, teethers, bottles, spoons, suckers, and brushes.
Medical Industry
Excellent biological characteristics and high-quality forming technology make LSR ideal for medical accessories such as catheters, joints, gastric tubes, laryngeal masks, dental brackets, negative pressure balls, incision protective covers, and balloons.
Electronics Industry
Waterproof, elastic, and high-precision LSR materials are used for silicone parts including waterproof seals, horn diaphragms, mobile phone cases, watch bands, buttons, and earphones.
Automobile Parts Industry
High permeability and efficient production process make LSR suitable for automotive silicone accessories including LED perspective mirrors, spark plug protectors, wire harness seals, and sealing strips.
