Specifications
Brand Name :
OUCO
Model Number :
OUCO-180T/220T
Certification :
CE, ISO9001
Place of Origin :
Wuxi, China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 sets per year
Delivery Time :
1 months
Packaging Details :
shipping container
Product Name :
180T-220T High Quality Efficiency Plastic Molding Machine With Energy-Saving Heating Device
Plastic Processed: :
PP, PC,PVC
Applicable Industries :
Manufacturing Plant, Food & Beverage Factory
Type :
Automation
Warranty: :
1 Year
Machinery Test Report: :
Provided
Selling Points :
Competitive Price
Video outgoing-inspection: :
Provided
Machine Style :
Horizontal
Condition :
New
Lead time (days) :
About 50 Days
Description

180T-220T High Quality Efficiency Plastic Molding Machine With Energy-Saving Heating Device
Advantage of OUCO GFServo Plastic Molding Machine

1. Cleanliness, the equipment is free from external pollution, and the equipment does not generate regeneration pollution to the outside world.

2. Precision, the equipment molds the best quality products with extremely high quality repeatability, highest equipment stability and safety under the shortest possible cycle conditions.

3. Servo oil-electric control system, high response, high precision, closed-loop control of pressure and speed.

4. The fully enclosed design of the product forming area, plus the positive pressure laminar flow air conveying device, the forming area can be an independent cleaning system.

5. The mold clamping machine hinge adopts a circulating lubrication system to reduce the pollution caused by lubricating oil and keep the machine clean.

6. Using new materials, the sliding foot is self-lubricating, reducing the pollution of lubricating oil.

7. Simultaneous ejection function of mold opening, shortening molding cycle and increasing production capacity.

Product Paraments

GF快速系列
机型 CWI-180GF CWI-220GF
合模装置 锁模力 Kn Clamping Force 1800 2200
拉杆间距 mm Space Between Tie-bars 520×520 570×570
开模最大开距 mm Clamping Stroke 500 550
最大模厚 mm Mould Thickness Max 550 600
最小模厚 mm Mould Thickness Min 200 220
模板尺寸 mm Size of Platen 755×755 830×830
顶出长度 mm Ejector Stroke 140 170
顶出力 Kn Ejector Force 53 80
顶针数 Ejector Quantily 5 9
注射装置 射胶装置 Injection Unit 420I 650I 650I 860I
螺杆直径 mm Screw Diameter 35 40 40 45 40 45 45 50
螺杆长径比 Screw L/D ratio 24 21 24 21 24 21 23 21
理论射胶容积 cm3 Shot Size 163 214 251 318 251 318 358 442
注射重量 (PS)g Shot Weight 150 196 231 293 231 292 329 406
oz 5.3 6.9 8.2 10.3 8.2 10.3 11.6 14.3
注塑压力 Mpa Injection Pressure 256 196 256 202 256 202 256 207
注射速度 mm/s Injection Speed 238 182 228 180
注塑速率 cm3/s Injection Rate 229 229 229 290 286 363 286 354
螺杆最大转速 rpm Screw Speed 400 400 400 350
其他 油泵电机功率 Kw Motor Power 36 48
油泵排量 L/min 220 275
电热功率 Kw Heater Power 8.9 10.9 10.9 13
机器净重 ton Machine Weight 6.5 7.5
机器尺寸(长×宽×高) mm Machine Dimension 5455×1620×1820 5830×1640×1870
