Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor
Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor
Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor
Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor
Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor
Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor
Specifications
Brand Name :
China
Model Number :
BMVF55
Certification :
ISO9001,CE
Place of Origin :
China
MOQ :
1 set
Price :
$1000-8000 per set
Payment Terms :
L/C, D/P, T/T
Supply Ability :
500set per month
Delivery Time :
2-5 days
Packaging Details :
1.plywood cases suitable for sea transportation 2.as customer's requirementcustomer's requirements.
Lubrication style :
Oil injected
Working pressure :
0.65-1.0 Mpa
Transmission way :
Direct driven(without belt)
OEM :
Acceptable
Cooling method :
Air Cooling
Capacity :
8.2-9.85 m3/min
Motor power :
55kw 75hp rotary screw air compressor
Type :
Permanent magnet frequency air compressor
Description

best place to buy air compressor

This series screw air compressor is permanent magnet variable frequency air compressor, more energy saving than the normal model. For example, for 37kw Frequency conversion air compressor compare with normal 37kw air compressor for one year 8000hours.

Frequency conversion air compressor 37kw: 183520kw
normal screw air compressor:281200kw
our Frequency conversion air compressorcan save 97680kw electricity
Advanges of BMVF22 Electric Stationary Screw Air Compressor
1. Wider range of speed regulation, higher accuracy of regulation, wider range of air supply pressure and higher energy efficiency.
2. The patented design of weak magnetic control, pressure control and simple and stable permanent magnet motor open-loop control can adapt to a variety of adverse working conditions and make the system more stable.
2. The patented design of weak magnetic control, pressure control and simple and stable permanent magnet motor open-loop control can adapt to a variety of adverse working conditions and make the system more stable.
4, motor and screw host coaxial, higher efficiency.
5,The BMVF series is the screw compressor industry to achieve the screw host, synchronous motor, permanent magnet control electrical control synchronous design, and to achieve the advantages of cooperation.

Specific performance is as follows:

Model
Working pressure
Capacity
Power
Outlet
Noise dB
Weight
Dimension
(MPa)
(m3/min)
(kW)
(A)
(kg)
(mm)
BMVF7.5
0.65-1.0
1.0-1.25
7.5
G3/4
72
200
880×510×800
BMVF11
0.65-1.0
1.5-1.85
11
G1
73
260
1000×670×1090
BMVF15
0.65-1.0
2.05-2.35
15
73
280
1000×670×1090
BMVF22
0.65-1.0
2.95-3.95
22
G1
74
390
1200×800×1120
BMVF37
0.65-1.0
5.05-6.35
37
G11/2
76
600
1340×850×1330
BMVF45
0.65-1.0
6.45-8.2
45
78
800
1480×1030×1365
BMVF55
0.65-1.0
8.2-9.85
55
80
810
BMVF75
0.65-1.0
10.5-13.1
75
G2
81
1280
1800×1190×1710
BMVF90
0.65-1.0
12.5-15.5
90
81
1300
BMVF110
0.65-0.8
22
110
DN65
82
1850
2700×1230×1730
BMVF132
0.65-0.8
24
132
82
2270

Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor

Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor

Oil Less Permanent Magnet Frequency 55KW 75kw Screw Air Compressor

Screw compressors meet the needs of users in the field of low-power and low-cost screw compressors. It has an efficient screw compression device, an efficient permanent magnet synchronous motor, and first-class permanent magnet variable control technology.

Customers Benefit

1. A economical and practical machine cansatisfy demand of user from the small power consumption, low price of screw compressor.
2. New generation of low consumption and high efficiency motor , larger starting torque, with SKY Bearing, low noise.
3. Dual nested Optimizer separator elements. reduce fluid carryover to a maximun of 1 ppm.
4. Computer-compatible microprocessor controller has simple graphic illustration of monitored functions
