Mining Drilling Rig Machine
Mining Drilling Rig Machine
Specifications
Brand Name :
KAISHAN
Model Number :
KGH4
Certification :
ISO9001
Place of Origin :
ZHEJIANG CHINA
MOQ :
1
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000
Delivery Time :
15DAYS AS GOT THE DOWN PAYMENT
Packaging Details :
wooden package as customer requirement
Condition :
new
Type :
Rotary Drilling Rig
Power Type :
Diesel
Rock Hardness :
Rock Hardness
After-sales Service Provided :
Engineers available to service mac
Description
1.Descriptions of crawler mounted blasthole drill KGH4

Product Name:Environment Friendly Open-Air Crawler mounted blasthole drill for surface mining

Model# : KGH4( KY125 Environmental Protection,With Dry-type Dust Collector and Reducer)

KGH4 was upgraded as the basis of the KY100,adding the dry-type dust collector and reducer.
Imported hydraulic motor,simulate the fan blade shape line,provide efficient and stable performance;The design of the coarse filtration and fine filtration, special environmental protection, high efficiency filter material, purification efficiency up to 99%; Excellent automatic control system, to realize automatic dust discharge, embody the people-oriented design concept.

Kaishan blasthole drill KGH4 is a diesel powered, self-propelled crawler mounted blasthole drill for mining and quarrying. It delivers the most performance from a compact production drill.

  • Solid platform ensures the longest durability in its class.
  • With optional high-pressure air, it's an exceptionally versatile rotary and DTH drill.
  • Highly maneuverable on narrow benches.

2.The Usage of Blasthole drill KGH4

1. The series portable drilling machine are used in a wide variety of Quarry ,Highway , Water and electricity , Surface mine,Mine project,blasting,ore and deep hole joint pipe drill work on the building project etc.
2. The series drilling rigs with air compressor,hammer together work , To blasting horizontal hole ,vertical holes ,inclines holes .

3.Specificaton of dust collector drill machine KGH4

Dia.of hole 105-140mm
Optium drilling depth 30m
Working pressure 10.5-24.6bar
Air consumption 15-25m3/min
Ground clearance 320mm
Feed power 10000N
Lift power 22KN
Speed of rotator 0-100rpm
Rotation torque 4000N·M
Climb capacity 30o
Traveling speed 0-2.5km/h
Dimensions 5400×2330×2020mm
Weight 7200KG
Power 90KW
Drilling Components
1.Hammer HD45S
2. Dia. Of rod Φ76mmm
2.Length of Rod 3m
3. Dia.of Bit Φ115mm



Other related blasthole drill

Recommend Drill Bit Φ90,Drill Hammer QCW930,Drill PipeΦ60x2000mm
Recommend Air Compressor
KAISHAN Brand
LGCY-15/13,LGCY-13/13 Diesel Portable Screw Air Compressor
