Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise
Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise
Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise
Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise
Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise
Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise
Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise
Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise
Specifications
Brand Name :
Kaishan
Model Number :
BMVF22
Certification :
ISO9001,CE
Place of Origin :
China
MOQ :
1 set
Price :
$1000-8000 per set
Payment Terms :
L/C, D/P, T/T
Supply Ability :
500set per month
Delivery Time :
2-5 days
Packaging Details :
1.plywood cases suitable for sea transportation 2.as customer's requirementcustomer's requirements.
Motor power :
22kw air compressor
Capacity :
2.95-3.95 m3/min
Working pressure :
0.65-1.0 Mpa
Voltage :
380V 50HZ 3phase can customize)
Lubrication style :
Oil lubrication
Transmission way :
Direct driven
Cooling method :
Air Cooled
Type :
Rotary screw compressor
Description

A high-effciency PM variable frequency screw air compressor has advantages in the following three areas:

The first is to have a highly effcient screw compression unit;

Secondly to have a high-effcient PM synchronous motor;

Thirdly to have first-clsaa PM variable control technology.

BOREAS PM variable frequency air compressor possessess significant technical advances in the following three areas.

Addition:

Compared to the ordinary PM variable frequency screw air compressor,BOREAS PM variable frequency screw air compressors have obvious technological advantages in the three aspects including screw compression unot efficiency,motor efficiency,dan control technology.

Technical parameters of BMVF screw air compressor

Model
Working pressure
Capacity
Power
Outlet
Noise dB
Weight
Dimension
(MPa)
(m3/min)
(kW)
(A)
(kg)
(mm)
BMVF7.5
0.65-1.0
1.0-1.25
7.5
G3/4
72
200
880×510×800
BMVF11
0.65-1.0
1.5-1.85
11
G1
73
260
1000×670×1090
BMVF15
0.65-1.0
2.05-2.35
15
73
280
1000×670×1090
BMVF22
0.65-1.0
2.95-3.95
22
G1
74
390
1200×800×1120
BMVF37
0.65-1.0
5.05-6.35
37
G11/2
76
600
1340×850×1330
BMVF45
0.65-1.0
6.45-8.2
45
78
800
1480×1030×1365
BMVF55
0.65-1.0
8.2-9.85
55
80
810
BMVF75
0.65-1.0
10.5-13.1
75
G2
81
1280
1800×1190×1710
BMVF90
0.65-1.0
12.5-15.5
90
81
1300
BMVF110
0.65-0.8
22
110
DN65
82
1850
2700×1230×1730
BMVF132
0.65-0.8
24
132
82
2270

Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise

Energy Saving Stationary 30HP 22kw Direct Driven Air Compressor Low Noise

Screw compressors meet the needs of users in the field of low-power and low-cost screw compressors. It has an efficient screw compression device, an efficient permanent magnet synchronous motor, and first-class permanent magnet variable control technology.

Customers Benefit

1. A economical and practical machine cansatisfy demand of user from the small power consumption, low price of screw compressor.
2. New generation of low consumption and high efficiency motor , larger starting torque, with SKY Bearing, low noise.
3. Dual nested Optimizer separator elements. reduce fluid carryover to a maximun of 1 ppm.
4. Computer-compatible microprocessor controller has simple graphic illustration of monitored functions
