75kw motor driven stationary screw air compressor low noise 455cfm 115psi
75kw motor driven stationary screw air compressor low noise 455cfm 115psi
Specifications
Brand Name :
kaishan
Model Number :
LG series
Certification :
ISO9001， CE
Place of Origin :
Zhejiang, China
MOQ :
1
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Delivery Time :
7-15 days after payment
Packaging Details :
Wooden package
Condition: :
new
Type :
Screw
Configuration :
Stationary
After-sales Service Provided :
Engineers available to service mac
feature 1 :
Low rotation,low vibration
feature 2 :
Energy-saving
Description

75kw motor driven stationary screw air compressor 455cfm 115psi LG-13/8

Specifications

1. better environment adaptability
2. famous brand in China mainland
3. ISO: 9001-2000
4. low noise

Advantages of screw type air compressor

  • simple and flexible travelling system
  • high efficiency and cost-effective
  • enviromental friendly
  • superior electric controllor system
  • safe and stable operation system
  • low noise and environmental friendly

Detailed specification of kaishan new air compressor

Structure Parameters
Capacity 13 m3/h
Working Pressure 8 bar
Rated Power 7.5 kw
Airend SKK-55LM-A
Drive Style Belt Connecting
Cooling System Wind-Cooled
Suction Temperature ≤40 °C
Pressure Normal Pressure
Relative Humidity ≤100%
Outlet Temperature Ambient Air Temperature +10 °C
Capacity 50 m3/min
Safety Valve Set Pressure 0.88 bar
Lubricating Oil Brand KAISHAN
Outlet Dimension G1
Sewage Outfall Dimension G1/2
Dimension Length 820 mm
Width 700 mm
Hight 1010 mm
Weight 340 kg
Motor Model Y2132S2-2
Speed 2878 rpm
Rated Power 7.5 kw
Service Factor 1.15
Safety Grade IP54
Insulation Grade F
Starting Method Direct Starting
Voltage 380 V or 420V
Frequency 50 Hz or 60 Hz
Rated Current 14.4A
Motor Weight 62 kg

About KAISHAN COMPANY:

1- Established in 1990 ,Specialized in this line more than 20 years.

2- National Free-inspection Product

3-Have advanced machining centers, automatic production line shape and heat treatmentequipment etc 500

sets from the United Kingdom, United States, Japan, Germany.

4-Exported to Australia/ Mongolia/ Japan/ South-Africa etc.

Our company other specifications products:

Model

Electrical power


kw

Outlet quantities


m3/min

Working pressure


Mpa

Weight


kg

Diemension


mm

LG-1.2/8
LG-1.0/10
LG-0.8/13

7.5

1.2
1.0
0.8

0.8
1.0
1.3

400

1100×800×1500

LG-1.7/8
LG-1.5/10
LG-1.2/13

11

1.7
1.5
1.2

0.8
1.0
1.3

450

1100×800×1500

LG-2.4/8
LG-2.2/10
LG-1.8/13

15

2.4
2.2
1.8

0.8
1.0
1.3

500

1100×800×1500

LG-3/8
LG-2.7/10
LG-2.3/13

18.5

3
2.7
2.3

0.8
1.0
1.3

600

1200×880×1550

LG-3.6/8
LG-3.2/10
LG-2.7/13

22

3.6
3.2
2.7

0.8
1.0
1.3

650

1200×880×1550

LG-5.2/7

LG-5/8

LG-4.5/10

30

5.2

5

4.5

0.7

0.8

1.0

1000

1300×1100×1650

LG-5.6/10

LG-4.8/13

LG-6.0/8

LGB-5.6/10

LGB-4.8/13

37

5.6

4.8

6.0

5.6

4.8

1.0

1.3

0.8

1.0

1.3

1050

1300×1100×1650
