Aluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kV
Aluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kV
Specifications
Brand Name :
Aluminium Conductor Medium Voltage Cable
Certification :
ISO,CE,IEC,TUV
Place of Origin :
Hebei，China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
100KM/Week
Delivery Time :
10work days
Packaging Details :
Wooden Drum
Insulation Material :
xlpe
Conductor Material :
Aluminum/copper
Sheath :
PVC
Armour :
STA
Type :
Medium Voltage
Voltage :
21/35kV
Description

Aluminium Conductor Medium Voltage Cable 3 core Steel Tape Armoured AL/XLPE/PVC/ 21/35kV



Application


This product is used in power grids or industrial installations with a rated voltage of 35kV or below. Having a job

High temperature, large current carrying capacity, simple structure, light weight, unrestricted installation by drop, medium

Features such as minimal damage, resistance to chemical corrosion and environmental stress, and easy maintenance.


Aluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kVAluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kVAluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kV


Construction


Conductor:Class 2 Aluminium/Copper circular, stranded

Conductor Screen:Semi-conductive XLPE (Cross-Linked Polyethylene)

Insulation :XLPE (Cross-Linked Polyethylene)

Insulation Screen :Semi-conductive XLPE (Cross-Linked Polyethylene)

Tape Plastic tape is applied over the screen

Filler Extruded polymeric material

Bedding PVC (Polyvinyl Chloride)

Armour :STA (Galvanized Steel Wire Armoured)

Sheath :Extruded PVC (Polyvinyl Chloride) type ST2

Aluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kVAluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kV

Specification


Specs
mm²

Conductor diameter
mm

Outer thickness of insulation
±1.0mm

Approx outer diameter of cable
mm

Approx cable weight
kg/km

Specs
mm²

Conductor diameter
mm

Outer thickness of insulation
±1.0mm

Approx outer diameter of cable
mm

Approx cable weight
kg/km

1×50

7.6±0.2

25.6

33.8

1370

3×50

7.6±0.2

256

68.1

4915

1×70

9.2±0.2

27.2

36.8

1855

3×70

9.2±0.2

27.2

71.7

5417

1×95

10.9±0.2

28.9

38.5

2019

3×95

10.9±0.2

28.9

75.8

6002

1×120

12.2±0.2

30.2

40.0

2188

3×120

12.2±0.2

302

80.3

7343

1×150

13.6±0.2

31.6

41.6

2373

3×150

13.6±0.2

31.6

83.5

7932

1×185

15.2±0.2

33.2

43.4

2598

3×185

15.2±0.2

33.2

87.3

8705

1×240

17.4±0.2

35.4

45.7

2907

3×240

17.4±0.2

35.4

92.5

9801

1×300

19.5±0.2

37.5

48.0

3224

3×300

19.5±0.2

37.5

97.4

10875

1×400

22.0±0.2

40.0

50.7

3689

3×400

22.0±0.2

40.0

103.5

12531

1×500

24.8±0.2

43.6

54.6

4252

3×500

24.8±0.2

43.6

111.8

14423

1×630

28.2±0.2

47.0

58.5

4917

3×630

28.2±0.2

47.0

119.8

16614

1×800

340±0.2

52.8

64.5

5795


Factory


Aluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kV


Projects

Aluminium Conductor Medium Voltage Cable 3 Core Steel Tape Armoured 21/35kV


FAQ

Why choose aluminum over copper for this cable?‌
Aluminum offers cost-effectiveness, lighter weight, and sufficient conductivity for medium voltage applications, though with slightly higher resistance than copper.

Where is this cable typically used?‌

Is this cable suitable for outdoor or underground use?‌
Yes, the steel tape armor provides excellent protection against moisture, soil pressure, and environmental stressors, making it ideal for both applications.

What are the advantages of steel tape armor?‌
It enhances mechanical strength, prevents damage during installation, and offers long-term reliability in demanding conditions.

How does the cable handle high voltage conditions?‌
The 21/35 kV rating ensures safe operation under medium voltage loads, with XLPE insulation minimizing electrical breakdown risks.

How can I place order?
A: You can contact us by email about your order details, or place order online.

Does your company provide OEM&ODM services?
A: Yes, we could accept OEM & ODM service, contact us now!
