0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24
0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24
Specifications
Brand Name :
Halogen-Free Flame-Resistant Cable
Certification :
ISO9001, CE, CCC, RoHS, VDE, cUL, CSA
Place of Origin :
Hebei，China
MOQ :
To be negotiated
Price :
To be negotiated
Payment Terms :
,L/C,T/T
Supply Ability :
100KM/Week
Delivery Time :
7-30 days based on different qty
Packaging Details :
Rolls, Wooden Drums, Steel Drums, Reels or customized
Usage :
power transmission and distribution
Insulation :
LSZH
Voltage :
0.6/1kV
Conductor :
Copper
Packing :
Drum, Carton or Customized
Standard :
EN 60332-3-24
Description

0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24


Application

A low-voltage fire-resistant power cable with LSZH insulation and sheath. The cable is widely used in places where fire safety is critical, such as commercial buildings, hospitals, airports,metro stations, shopping malls, schools and tec.


Construction


1.Conductor : Class 1 or 2 copper conductor

2.Insulation:LSZH (Low Smoke Zero Halogen)
3.Inner Sheath:LSZH (Low Smoke Zero Halogen)
4. Outer Sheath:LSZH (Low Smoke Zero Halogen)

0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24


Standards


IEC/EN 60332-3-24, IEC 60331



Specifications


Spec
mm²

Conductor diameter mm

Approx outer diameter of cable

mm

Approx cable weight

kg/km

NH

ZAN

ZBN

ZCN

NH

ZAN

ZBN

ZCN

3×16

5.0

18.9

192

192

19.2

659.4

713.1

719.2

680.1

3×25

6.1

22.5

22.5

22.5

22.5

974.7

1044.6

1051.8

996.1

3×35

72

24.8

24.8

24.8

24.8

1274.1

1361.6

1369.6

1300.0

3×50

8.4

27.9

28.3

27.9

27.9

1659.7

1806.0

1775.4

1692.0

3×70

10.0

32.0

32.4

32.0

32.0

2320.7

2510.1

2474.6

2362.4

3×95

12.0

36.4

36.9

36.4

36.4

3132.4

3375.7

3334.7

3185.7

3×120

12.2

37.5

37.9

37.5

37.5

3797.7

4053.5

4010.8

3853.6

3×150

13.6

41.8

41.8

41.8

41.8

4681.2

4957.1

49455

4749.1

3×185

15.2

46.3

46.3

46.3

46.3

5813.6

6154.0

6133.9

5896.1

3×240

17.4

51.9

51.9

51.9

51.9

7519.6

7947.6

7923.0

7621.7

3×300

19.5

572

57.2

57.2

57.2

9355.8

9847.1

9847.1

9478.3

3×400

22.0

64.0

64.0

64.0

64.0

11858.3

12473.0

12473.0

12009.4

4×1.5

1.39

12.0

12.3

12.3

12.3

186.2

201.4

201.4

201.4

4×2.5

1.76

12.9

13.2

13.2

12.9

236.7

252.8

252.8

241.3

4×4

2.22

14.0

14.3

14.3

14.0

3092

327.2

327.2

314.2

4×6

2.74

15.3

15.6

15.6

15.3

402.2

422.6

422.6

407.8

4×10

4.0

18.3

18.6

18.6

18.6

588.5

634.7

640.6

607.4

4×16

5.0

21.0

21.0

21.0

21.0

845.5

900.0

906.7

863.1

4×25

6.1

24.7

24.7

24.7

24.7

1250.8

1328.7

1336.6

1274.7

4×35

72

27.4

27.4

27.4

27.4

1643.6

1741.3

1750.2

1672.6

4×50

8.4

30.9

31.4

30.9

30.9

2163.3

2326.9

2292.5

2199.4

4×70

10.0

35.5

35.9

35.5

35.5

3031.9

3243.8

3203.9

3078.4

4×95

12.0

40.5

41.0

40.5

40.5

4098.6

4370.6

4324.5

4158.1

4×120

12.2

41.8

42.3

41.8

41.8

4998.3

5285.4

5236.4

5060.6

4×150

13.6

46.4

46.4

46.4

46.4

6136.1

6444.3

6430.9

6211.8

4×185

15.2

51.6

51.6

51.6

51.6

7649.6

8031.2

8006.8

7741.8

4×240

17.4

57.8

57.8

57.8

57.8

9896.6

10376.0

10346.5

10010.5

4×300

19.5

63.7

63.7

63.7

63.7

12314.4

12861.8

12861.8

12451.0

4×400

22.0

71.3

71.3

71.3

71.3

15606.1

16291.7

16291.7

15774.6

5×1.5

1.39

13.0

13.3

13.3

13.3

218.6

235.5

235.5

235.5

5×2.5

1.76

14.0

14.3

14.3

14.0

280.8

298.8

299.5

285.8

5×4

2.22

152

15.5

15.5

15.2

369.9

391.0

391.0

375.4

5×6

2.74

16.6

16.9

16.9

16.6

484.6

508.5

508.5

490.7

5×10

4.0

20.4

20.4

20.4

20.4

7192

769.4

776.9

7356

5×16

5.0

23.1

23.1

23.1

23.1

1031.4

1097.7

1106.4

1052.2

5×25

6.1

27.2

27.2

27.2

27.2

1533.7

1628.8

1637.6

1562.1

5×35

72

30.1

30.1

30.1

30.1

2021.3

2140.4

2150.2

2055.8

5×50

8.4

34.2

34.7

34.2

34.2

2680.5

2876.9

2838.3

2723.7

5×70

10.0

39.3

39.8

39.3

39.3

3760.0

4014.9

3970.1

3815.8

5×95

12.0

45.1

45.5

45.1

45.1

5107.2

5436.4

5383.7

5178.7

5×120

12.2

46.3

46.7

46.3

46.3

6204.7

6550.6

6495.8

6279.6

5×150

13.6

51.6

51.6

51.6

51.6

7643.2

8020.9

8004.6

7734.5

5×185

15.2

57.4

57.4

57.4

57.4

9525.2

9992.5

9963.3

9636.4

5×240

17.4

64.2

64.2

64.2

64.2

12322.0

12909.5

12874.3

12459.9



Contact us for more details



0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24

0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24

0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24

0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24

0.6/1kV Fire Resistant Cable CU/LSZH/LSZH EN 60332-3-24



FAQ


1.What is our payment term?

Our payment term is T/T 30% advanced, then the balance paid before picking up the goods or L/C at sight.


2.What is the lead time?
The lead time usually is 7– 30 working days.

3.What is the package of the cable?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement.

4.Could we provide the free sample for customer?
Sure, we provide the free sample for customer to checking.

5.Does your company accept OEM production?
Yes, could print your company name.

Please feel free to leave your requirement, We will reply you in 12 hours.
