Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Specifications
Brand Name :
Luma
Model Number :
ORANGE-001
Place of Origin :
Zhongshan Guandong province China
MOQ :
4
Price :
USD 40 .2 brake /USD 37.8 Swivel/USD 36.6 Rigid
Payment Terms :
L/C,wechat,alipay
Supply Ability :
100000
Delivery Time :
5-10days
Packaging Details :
bags and cartons
Inches :
6 inches
Braketype :
Brakin Side/ brake/ Swivel/ Fixed
Productname :
Industrial Wheel Casters
Color :
Black / Grey / Blue
Usage :
Industrial Manufacturing/ Warehousing and Logistics /Medical and Healthcare/ Commercial and Retail/ Office and Institutional Settings/ Home and Furniture
Material :
PU
Finish :
Zinc Plated
Bearingtype :
Ball Bearing
Wheeltype :
Braking Side brake Swivel Fixed
Mountingtype :
Top Plate
Sample :
1pcs ，price add 50%
Description
Impact-resistant Industrial Heavy Duty Stainless Steel Spring Castors with PU Wheels
Stainless Steel Double Spring with Aluminum Core & Polyurethane Wheel Heavy-Duty Caster
Material Composition
  • Housing: 304/316 stainless steel (corrosion-resistant, suitable for harsh environments)
  • Spring System: Dual spring shock absorption (reduces impact by 40-60% compared to single spring)
  • Wheel Core: Aluminum alloy (lightweight yet high load capacity)
  • Wheel Surface: Polyurethane (non-marking, abrasion-resistant, hardness 85-95A)
Specialized Design Features
  • Sealed ball bearings (IP54 rating, dust/water-resistant)
  • Bolt-hole or swivel mounting options
  • Optional brake systems (side-lock or total-lock)
Product Specifications
Braking/Activation/Orientation Braking / Side braking / Swivel / Fixed
Size 5 inches
Wheel Material PU
Base Plate Support Material Q235
Bearing 6202 Bearing
Installation Height 190
Base Plate Size 115*100
Hole Distance 82*72
Box Size 49*28.5*25cm
Matching Specifications
  • Set 1: 2 brakes + 2 fixed
  • Set 2: 2 swivel + 2 fixed
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
Load Capacity
Condition Dynamic Load (per caster) Static Load (per caster)
Standard Use 300-500 kg 800-1,200 kg
High-Temp (≤120°C) 250-400 kg 600-900 kg
Primary Applications
  1. Automotive Industry: Assembly line tool carts, battery handling equipment, paint shop trolleys
    Advantages: Electrostatic dissipation, oil/chemical resistance, low noise (<65 dB)
  2. Other Heavy-Duty Scenarios: Aerospace machinery transport, medical imaging device movers, warehouse logistics
Technical Data Summary
  • Temperature Range: -30°C to +120°C
  • Wear Resistance: Polyurethane tread lifespan ≈ 3,000 km (on concrete floors)
Why Choose This for Automotive Needs?
  • Corrosion Resistance: Withstands automotive chemicals (e.g., brake fluid, lubricants)
  • Shock Absorption: Dual springs protect sensitive equipment during movement
  • Floor Protection: Polyurethane wheels prevent scratches on epoxy-coated automotive floors
Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications Stainless Steel Industrial Wheel Casters with Dual Spring Shock Absorption and Polyurethane Wheels for Heavy-Duty Applications
