HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals
HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals
HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals
HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals
HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals
HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals
Specifications
Brand Name :
CENO
Model Number :
BCN16B-30-01HD
Certification :
CE,RoHS,ISO9001,UL
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
T/T,Paypal, Western Union
Supply Ability :
500pcs per month
Delivery Time :
1 week
Packaging Details :
Carton/As request
Circuit & curren :
2 circuits * 12.5A; 1 * 1000M Ethernet; 1 * USB2.0 Signal; 1 * HDMI Signal
Voltage :
0 ~ 240 VAC/VDC
Dielectric strength :
≥300VAC@50Hz
Isolation resistance :
≥100MΩ@300VDC
Contact resistance wave :
≤ 30mΩ
Working temperature :
-20°C~+60°C
Working humidity :
60 %RH
IP protection grade :
IP52
Operating speed :
0~300rpm
Outer diameter :
Ø16mm
Contact material :
Precious Metal
Housing material :
Aluminium Alloy
Lead wire size & length :
As customized
Description

HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals

BCN16B-30-01HD is CENO Capsule Slip Ring combined Electric Power, Ethernet, USB and 1 channel HDMI signal. Capsule slip ring are often offered in a compact size with flange like small slip ring, used for electrical power transmission, data transfer between a stationary and a rotating part. They are easily installed and widely used in small and medium-sized equipment, such as speed dome camera, intelligent toys, stage lights and drones, etc. For more information please contact us.

Features

  • Compact structure + easy installation
  • Integrate Ethernet, HDMI, USB with Power and can be customized
  • Stable transmitting, no string code, can be integrate various signal /data

Applications

  • Instrument and apparatus
  • High speed ball
  • Drones
  • Video monitoring system
  • Medical equipment

Optional

  • Circuit, Voltage, Current
  • Signals and data
  • Contact / Housing Materials
  • Protection grade
  • Working speed & temperature




Specification

BCN16B-30-01HD Specification
Current & Circuits 2 circuits * 12.5A; 1 * 1000M Ethernet; 1 * USB2.0 Signal; 1 * HDMI Signal
Rating Voltage 0 ~24 VAC/VDC
Dielectric strength ≥300VAC@50Hz
Isolation resistance ≥100MΩ@300VDC
Contact resistance wave ≤ 30mΩ
Working temperature -20°C~+60°C
Working humidity 60 %RH
IP protection grade IP52
Operating speed 0~300rpm
Outer diameter Ø16mm
Contact material Precious Metal
Housing material Aluminium Alloy
Lead wire size & length Customized



Outline Drawing

HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals




Why with CENO

CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.

HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals

Certification

ISO9001,CE,RoHS,UL,Explosion-proof

HDMI Capsule Slip Ring combined Electric Power Ethernet and USB signals

CENO Advantage

Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.

Service CENO provides

24 hours,7days consultant service.

Mass and customized production.

Solution offerring for 360° rotation system.

Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
