L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
Specifications
Color :
black, red
Working Temperature :
-20oC - +100oC
hardness :
80-98shore A
Brand Name :
3A Rubber
Model Number :
3A2006
Certification :
ROHS/FCC/SGS
Place of Origin :
China
MOQ :
10pieces
Price :
negotiation
Payment Terms :
T/T,L/C,Paypal,Western Union
Supply Ability :
10000kgs per month
Delivery Time :
10 working days after received your payment
Packaging Details :
Packed in cartons
Size :
L035-225
Material :
NBR, CSM/SBR or TPU
Description
L Type Flange Cast Iron Polyurethane Coupling, Flexible Jaw Coupling
Product Overview

L type rubber coupling, L polyurethane coupling, L PU coupling designed for reliable power transmission in industrial applications.

Specifications
  • Material: Cast iron GG25
  • Good stability
  • Easy to maintain
  • ISO9001-2000 certificate
Coupling Features
  • Jaw coupling/HRC coupling/KC coupling/FL coupling
  • Flange cast iron, Insert Rubber
  • Taper bore universal series
  • Keyway dimensions conform to DIN6885, GB1095-1979 standards
L Type Flange Cast Iron GG25 Polyurethane Coupling with 80-98 Shore A Hardness and ISO9001-2000 Certification
Dimensions Table
Size Type A B D E Standard Metric Bore Inch Bore Bore Min Bore Max
L03511620.56.6--3381/8"3/8"
L05012843.215.6--66153/16"5/8"
L07013550.819--99193/16"3/4"
L07514554.721--99253/16"1"
L09015454.721--99283/16"1 1/8"
L09515463.725.5--99283/8"1 1/8"
L099164.572.527--1212357/16"1 3/8"
L100164.588.535--1212357/16"1 3/8"
L11018510843--1515481/2"1 7/8"
L150196115.445--1515485/8"1 7/8"
L1901115133.454101.61919555/8"2 1/4"
L2251127153.4641081919653/4"2 5/8"
Additional Standard Sizes
Polyurethane Coupling
GR14, GR19, GR24, GR28, GR38, GR42, GR48, GR55, GR65, GR75, GR90, GR100, GR110, GR125, GR140, GR160, GR180
MT1, MT2, MT3, MT4, MT5, MT6, MT7, MT8, MT9, MT10, MT11, MT12, MT13
HRC70, HRC90, HRC110, HRC130, HRC150, HRC180, HRC230, HRC280
L35, L50, L70, L75, L90/95, L99/100, L110, L150, L190, L225, L276
FALK-R 10R, 20R, 30R, 40R, 50R, 60R, 70R, 80R
Rubber Coupling
Hb80, Hb95, Hb110, Hb125, Hb140, Hb160, Hb180, Hb200, Hb240, Hb280, Hb315
HRC70, HRC90, HRC110, HRC130, HRC150, HRC180, HRC230, HRC280
L35, L50, L70, L75, L90/95, L99/100, L110, L150, L190, L225
NM50, NM67, NM82, NM97, NM112, NM128, NM148, NM168, NM194, NM214, NM240, NM265
Gear 3J, 4J, 5J, 6J, 7J, 8J, 9J, 10J, 11J

Special sizes can be built according to buyer's drawings and specifications.

Important: When making an enquiry, please confirm the product number and quantity for accurate pricing and delivery.
