Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Specifications
Brand Name :
E-link
Model Number :
LNK-TCU1000
Certification :
ROHS,FCC,CE
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiation
Payment Terms :
L/C,T/T,Western Union,MoneyGram,Paypal
Supply Ability :
1000 pcs/month
Delivery Time :
3-12 working days
Packaging Details :
Network Adapter Standard Export Package
Keywords :
Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
Dimensions (WxDxH) :
78 x 27 x 18 mm
Weight :
46g
Operating Temperature :
0°C ~ 60°C (32° ~ 140°F)
MTBF :
> 100,000 hrs
Description

Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter

Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter Advantages

► 1 x 10/100/1000Mbps RJ45 Slot + 1 x TYPE-C USB3.0 Slot

► Supports Gigabit networking over USB 3.0

► IEEE 802.3, 802.3u and 802.3ab (10BASE-T, 100BASE-TX, and 1000BASE-T) compatible

► Powered directly from the USB ports

► Crossover Detection & Auto-Correction (Auto MDIX)

► IEEE 802.1Q VLAN Tagging support

► Jumbo Frame support

► Supports Checksum Offload (IPv4, IPv6, TCP, UDP) and Large Send Offload

► Activity and Link LED indicators

► Compact, lightweight design for maximum portability

Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter Overview

E-link LNK-TCU1000 Series USB-C Network Interface Card designed for Laptop/PC/Tablet that with Type-C interface and need to access Fast and Stable internet through UTP Cable. With this USB-C LAN Card, Network Connection is more stable and quicker than Wifi access. It can offer 1000Mbps Internet access, It provides up to 2000Mbps full-duplex bandwidth capacity. In addition, with advanced functions like VLAN filtering packet processing, the adapter provides added performance, flexible configuration and secure networking for users in a standard-based environment.

Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter Technical Indexes

Standards:

IEEE 802.3 10BASE-T

IEEE 802.3u 100Base-TX Fast Ethernet

IEEE 802.3ab 1000BASE-T Gigabit Ethernet

IEEE 802.3az Energy Efficient Ethernet (EEE)

IEEE 802.1q VLAN tagging

Chipset ID:

Realtek RTL8153B

Network Transfer Rate:

14,880pps (10Mbps)

148,800pps (100Mbps)

1,488,000pps (1000Mbps)

Jumbo Frame Support:

9K max.

Other:

Supports Checksum Offload (IPv4, IPv6, TCP, UDP) and Large Send Offload

Software

OS Compatibility:

Windows® XP, Vista, 7, 8, 8.1, 10, 11

Windows® Server 2008 R2, 2012, 2012 R2, 2016, 2019

MacOS 10.8 to 10.15, VLAN tagging is currently not supported in macOS

Linux Kernel up to 5.17

UEFI UNDI

Interface

USB:

1 x USB-C 3.0

RJ45:

1 x RJ-45 10/100/1000Mbps LAN port

Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter Ordering Information

Model

Description

LNK-TCU1000

Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter

Mounting Options

► Desktop

Power Options

► No need for an external power adapter (bus powered)

Package Contents

► USB 3.0 Gigabit Ethernet Adapter x 1

► Quick installation guide x 1


Micro Mini USB 3.0 to Gigabit Ethernet NIC Network Adapter
