Specifications
Brand Name :
E-link
Model Number :
LNK-D4K-MM-S
Certification :
CE, FCC, RoHS
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiated
Payment Terms :
T/T,PayPal
Supply Ability :
1000pcs/mouth
Delivery Time :
5-12working days
Packaging Details :
standard export package
Operating Temperature :
32° to +112° F. (0° to +50° C)
Storage Temperature :
-40° to +185° F. (-40° to +85° C)
Dimensions (L x W x H) :
69mm x 42 mm x 18.2 mm
Net Weight :
100 g
DVI Input / DVI Output :
1x DVI-D 18+1 Male connector
Optical :
1x SFP+ port
Description

Mini 4KX2K DVI Fiber Transceiver MM 300M Auto EDID

Advantage

► Support DVI 1.0 and HDMI v1.4

► Support EDID pass-through.

► Support resolutions up to 3840x2160/30P

► Support 3840*2160/60P(YUV 420)

► Plug and Play ,Built-in EQ(Receiver)

► Support 4K/30P@ Single-Link

► Two fiber,2-ways

Overview

E-link Mini 4Kx2K DVI is High-Definition Multimedia Interface recently has become increasingly popular

in the application of video and audio transmission system, DVI Fiber Optic Extender uses one fiber without

any copper wire inside, where radio frequency interference phenomenon is literally ruled out, which shows

the advantage of high performance and good signal quality as well as low cost.

The LNK-D4K-MM series is a high performance 4K Optical Extender that transmits high resolution DVI signals

over extreme distances using one fiber. This extender supports HDMI v1.4 signals with resolutions up to

4K (3840*2160/30p) over cable distances up to 300m.


Mini 4KX2K DVI Fiber Transceiver MM 300M Auto EDID

Technical Indexes

Parameter

Specifications

Compliance

DVI1.0,HDMI v1.4

Bandwith

10.2 Gbps

Supported Resolutions

3840x2160/30P,3840*2160/60P(YUV 420), 4096*2160/60P(YUV 420)

Digital Audio Support

7.1 channel LPCM, 192 kHz, 24-bit audio capability

Connections

DVI Input / DVI Output

1x DVI-D 18+1 Male connector

Optical

1x SFP+ port

Cable

Fiber Cable

50/125μ OM3 Multi-Mode Fiber:≤300m

DDC Support

EDID Support

Support EDID pass-through

HDCP Pass-through Support

Yes, Support the HDCP 1.4 pass-through

Mechanical

Construction

High-impact Alufer enclosure

Dimensions (L x W x H)

69mm x 42 mm x 18.2 mm

Net Weight

LNK-D4K-SM-S: 100 g LNK-D4K-SM-R: 100 g

Application

Mini 4KX2K DVI Fiber Transceiver MM 300M Auto EDID

Ordering Information

Model

Description

LNK-D4K-MM-S

Mini 4KX2K DVI Fiber Sender Auto EDID,DC5V1A

LNK-D4K-MM-R

Mini 4KX2K DVI Fiber Receiver Auto EDID,DC5V1A
