Specifications
Brand Name :
E-link
Model Number :
LNK-KVM-DVI-1D1BA1GO
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiation
Payment Terms :
L/C,T/T,Western Union,MoneyGram,Paypal
Supply Ability :
1000 pcs/month
Delivery Time :
3-12 working days
Packaging Details :
Carton Packaging
The warranty :
1-year warranty
Dimensions (WxDxH) :
148*115*28mm
Operating Temperature :
-5℃ ~ +70℃
Humidity :
5% ~ 90%
Power dissipation :
MAX 6W
Power supply :
The power adapter: DC 12V/1A
Description

1Ch 1080P DVI + USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + 1Ch GPIO over Fiber Extender


Advantages

► Transmits DVI video signals up to 60km over one fiber optic cable;

► Support video resolution up to 1920*1200P@60Hz;

► Support keyboard and mouse signal transmission;

► Support external stereo audio bi-directional transmission;

► Support RS232 signal unidirectional transmission, baud rate self-adaptive;

► Support general-purpose input/output (GPIO) signal;

► Support HDMI loop out

► Compliance with DVI 1.0 and HDCP 1.2 standard;

► High compatibility, can auto-match source and display device;

► Built-in automatic adjustment system, make the image smooth, clear and stable;

► Built-in ESD protection system;

► Simple to install, plug and play


Overview

The LNK-KVM-DVI-1D1BA1GO Fiber optic extender provides extension of DVI signals long distances over one fiber optic cable, it supports high resolution up to 1080P, KVM, RS232, GPIO signal and external audio transmission function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.


Ordering Information

Model

Description

LNK-KVM-DVI-1D1BA1GO

1Ch 1080P DVI + 1Ch USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + 1Ch GPIO over Fiber Extender, HDMI Loop Out, SMF, 20KM



1Ch 1080P DVI + USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + 1Ch GPIO over Fiber Extender



Application

1Ch 1080P DVI + USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + 1Ch GPIO over Fiber Extender
