4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
4K 2X2 Video Wall Controller & Player
Specifications
Brand Name :
E-link
Model Number :
LNK-VWCP
Certification :
CE
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability :
100000PCS/Month
Delivery Time :
7-10 working days
Packaging Details :
Industrial PoE Switch Standard Carton Packaging
Weight(1U) :
1100g
Case size :
217mm*162mm*47mm
Power :
DC12V
Control code :
IR case key
Description

4K 2X2 Video Wall Controller & Player


Technical Indexes

Name

Specification

Input signal

VGA

HD15 interface and link with 1 audio interface of 3.5

Support 640x480/85Hz to 1920x1200/60Hz

HDMI

HDMI1.4 (HDCP1.4), HDMI embedded audio; The maximum input resolution supports 3840 x 2160/60Hz (RGB420), the maximum output resolution supports single screen 3840x 2160/30Hz, and the full screen resolution is 3840 x 2160/30Hz * 4

DVI

DVI-I interface (24+5), with a maximum resolution support of 3840x2160/30Hz

Video

Automatic identification the system of NTSC,PAL and SECAM, link with 1 audio interface of 3.5

USB

Standard interface of 2.0,can insert U disk, embed audio;

Support video,image,MP3,MP4,TXT ；

Output signal

HDMI interface

4 HDMI output, support joint pattern of 2x2, 1x1, 1x2, 1x3,1x4,4x1, 3x1,2x1,;Support 3840*2160/30Hz 1920*1080P/60Hz,1280*720/60Hz;

Audio

3.5 Audio interface, support left and right channels and stereo, AV signal switch synchronously

Splicing scale

Simple four-piece splicing The input signal supports 90°180°270° full screen rotation (resolution is 1920x1080p or below), and the output screen supports 180° mirror/flip;

Control code

IR case key

Power

DC12V

Case size

217mm*162mm*47mm

Weight(1U)

1100g


Overview

This product is a high-definition image splicing processor specifically designed for LCD TVs, ultra narrow edge LCD screens, and projectors. It supports 4 HDMI signal outputs per unit and can be connected to LCD TVs or other display devices. Various splicing modes can be customized according to user needs.

Application

4K 2X2 Video Wall Controller & Player

4K 2X2 Video Wall Controller & Player


Ordering Information

Model

Description

LNK-VWCP

4K 2X2 Video Wall Controller & Player

HDMI/USB(Flash drive )/DVI/VGA input
