Specifications
Brand Name :
QiJie
Model Number :
qijie
Certification :
qijie
Place of Origin :
HeBei,China
MOQ :
1 rolls
Price :
Discuss
Payment Terms :
30%TT in advance,Balance before loading
Supply Ability :
1500 Roll/Rolls per Week
Delivery Time :
within 7-30 days
Packaging Details :
Wooden carton
Material :
Stainless Steel Wire, 316, 304, plain steel galvanized
Technique :
Welded Mesh
Application :
Screen, Protecting Mesh
Hole shape :
Square Hole, rectangule hole
Normal blade type :
BTO-22, BTO-30, CBT-60, CBT-65
Email :
devin@industrialmetalmesh.com
whatsapp :
+8615369013183
Description
Security Bto-22 Blade Stainless Protective Welded Steel Razor Barbed Wire Mesh Roll​

Razor Barbed Wire is also named concertina razor wire, razor fencing wire, razor blade wire or dannert wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.

Outside Diameter
No. of Loops
Standard Length per Coil
Razor Type
Notes
450mm
33
7M-8M
CBT-60, 65
Single Coil
500mm
56
12M-13M
CBT-60, 65
Single Coil
700mm
56
13M-14M
CBT-60, 65
Single Coil
960mm
56
14M-15M
CBT-60, 65
Single Coil
450mm
56
8M-9M (3clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type
500mm
56
9M-10M (3clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type
600mm
56
10M-11M (3clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type
600mm
56
8M-10M (5clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type
700mm
56
10M-12M (5clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type
800mm
56
11M-13M (5clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type
900mm
56
12M-14M (5clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type
960mm
56
13M-15M (5clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type
980mm
56
14M-16M (5clips)
BTO-10, 12, 18, 22, 28, 30
Cross Type

Security Bto-22 Blade Stainless Protective Welded Steel Razor Barbed Wire Mesh Roll

Security Bto-22 Blade Stainless Protective Welded Steel Razor Barbed Wire Mesh Roll

Application of concertina razor barbed wire

Razor Barbed Wire is widely used in airport , prison, government, bank, and also in living wall, personal house, villatic wall, window, autobahn, railway and border of the fence.

Packing of concertina razor barbed wire

compression rolls, water-proof paper inside, woven bag outside or in carton

Security Bto-22 Blade Stainless Protective Welded Steel Razor Barbed Wire Mesh Roll

Security Bto-22 Blade Stainless Protective Welded Steel Razor Barbed Wire Mesh Roll

Weave characteristics of concertina razor barbed wire

twist and weave, fastness ,beautiful; galvanizing after weaving, galvanizing before weaving. It is divided to electrical galvanized ,hot - dipped galvanized, plas-tic coating, stainless steel, etc.

Advantages of concertina razor barbed wire

Razor barbed wire mesh is a new kind of protective fencing with such advantages as beautiful appearance,economical cost and practicality.

Welded razor mesh fence:

The razor wire can welded to mesh panel with a frame as the fence installed on the prison wall, the hole shape can be rectangle and diamond.

1>Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
2>Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.
Hole shape Mesh width Suited blade specifications
Square hole, diamond 1.2m ~ 2.4m BTO-10.12.22.28.30
Square hole, diamond 1.2m ~ 2.4m BTO-10.12.22.28.30
Square hole, diamond 1.2m ~ 2.4m BTO-10.12.22.28.30
Square hole, diamond 1.2m ~ 2.4m BTO-10.12.22.28.30
