Durable Innolux LCD Panel / 5 Inch LCD Panel Replacement 640×480 Outline 117.65×88.43×5.9 Mm
Durable Innolux LCD Panel / 5 Inch LCD Panel Replacement 640×480 Outline 117.65×88.43×5.9 Mm
Durable Innolux LCD Panel / 5 Inch LCD Panel Replacement 640×480 Outline 117.65×88.43×5.9 Mm
Durable Innolux LCD Panel / 5 Inch LCD Panel Replacement 640×480 Outline 117.65×88.43×5.9 Mm
Durable Innolux LCD Panel / 5 Inch LCD Panel Replacement 640×480 Outline 117.65×88.43×5.9 Mm
Durable Innolux LCD Panel / 5 Inch LCD Panel Replacement 640×480 Outline 117.65×88.43×5.9 Mm
Specifications
Brand Name :
INNOLUX
Model Number :
ZJ050NA-08C
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1 Piece
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Size :
5.0 inch
Resolution :
640×480
Active Area :
101.57×76.18 mm
Surface :
Antiglare
Frequency :
60Hz
Description

Normally White ZJ050NA-08C 5.0 inch INNOLUX 640×480 Outline 117.65×88.43×5.9 mm Frequency 60Hz

ZJ050NA-08C Basic Information

Panel Model ZJ050NA-08C
Panel Brand INNOLUX
Descrition a-Si TFT-LCD ,5.0 inch, 640×480
Panel Type a-Si TFT-LCD
Operating Temperature -20 ~ 70 °C
Storage Temperature -30 ~ 80 °C

ZJ050NA-08C Mechanical Features

Dot Resolution 640(RGB)×480 (VGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 160 PPI
Aspect Ratio 4:3 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.053×0.159 mm (H×V)
Pixel Pitch 0.159×0.159 mm (H×V)
Weight 67g (Typ.)
Surface Antiglare
Active Area 101.57×76.18 mm (H×V)
Outline Dimension 117.65×88.43 mm (H×V)
Outline Depth 5.7±0.2 mm
Landscape or Portrait Landscape type
Touch Panel Without

ZJ050NA-08C Optical Features

Display Mode TN, Normally White, Transmissive
Brightness 250 cd/m² (Typ.)
Contrast Ratio 500 : 1 (Typ.) (Transmissive)
Display Color 16.7M (8-bit)
Color Gamut 50% NTSC (CIE1931)
Response Time 10/15 (Typ.)(Tr/Td)
Viewing Angle 70/70/50/70 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction 6 o'clock
White color Chromaticity Wx:0.310; Wy:0.330
White Variation 1.33/1.43 (Max.)(9 points)
Sunlight Readable N

Packaging & Delivery

Packaging Details:

Safey package

Plastic trays inside

2 layes of cartons

Fragile sign on top

Can be customize 3.5 inch spare parts auo used lcd panel

Delivery Detail: 1-3 Working Days

Why do you choose us?

• Quick response to clients' enquiries within 24hrs.

• More than 6-year experience in LCD screen field and professional team communication team.

•Value quality and long-term cooperation to reach win-win relationship.

Pls contact to us for more stock information: salespm@nselectronic.com.hk
