Specifications
Brand Name :
CPT
Model Number :
CLAA070WP03XG
Certification :
ISO9001
Place of Origin :
Japan，Korea
MOQ :
1 piece
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
100 PCS PER DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Type :
a-Si TFT-LCD , Panel
Panel Size :
7.0 inch
Resolution :
800(RGB)×1280 , WXGA
Display Mode :
HFFS, Normally Black, Transmissive
Brightness :
450 cd/m² (Typ.)
Contrast Ratio :
700:1 (Typ.)
Display Colors :
262K (6-bit) , CIE1931 60%
Response Time :
30 (Typ.)(Tr+Td)
Description

CPT CLAA070WP03XG 7 inch tft lcd display , industrial display solutions

CPT CLAA070WP03XG General Features

Panel Brand : CPT
Panel Model : CLAA070WP03XG
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 7.0 inch
Resolution : 800(RGB)×1280 , WXGA
Display Mode : HFFS, Normally Black, Transmissive
Active Area : 94.2×150.72 mm
Outline : 104.32×161.67×4.05 mm
Surface : Glare (Haze 0%), Hard coating (3H)
Brightness : 450 cd/m² (Typ.)
Contrast Ratio : 700:1 (Typ.)
Display Colors : 262K (6-bit) , CIE1931 60%
Response Time : 30 (Typ.)(Tr+Td)
Viewing Angle : 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : WLED
Signal Interface : LVDS (1 ch, 6-bit) , 31 pins
Input Voltage : 3.3V (Typ.)

Our Service

• Long lasting product cycle for continuity thru all phases of project rollouts and servicing

• Easy-to-install console, Open Frame chassis-mount display

• Slim dimensions enable better enclosure designs

• Multiple mounting options (100mm VESA mount and side brackets)

• All steel construction provides rugged frame for public use environments

• Two independent touch points (with Windows 7 OS)

• Improved power efficiency and reduced consumption

• TUV, CE, UL, CUL, FCC-B, RoHS, and IPX1 approvals

CPT CLAA070WP03XG Optical Features

Display Mode : HFFS, Normally Black, Transmissive
Brightness : 450 cd/m² (Typ.)
Contrast Ratio : 700 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Color Gamut : 60% NTSC (CIE1931)
Response Time : 30 (Typ.)(Tr+Td)
Viewing Angle : 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : Symmetry
White color Chromaticity : Wx:0.310; Wy:0.330
White Variation : 1.25/1.39 (Typ./Max.)(9 points)

Company Strength

1. ISO9001 certificated, Factory Direct Supplied

2. RoHS Compliant, Lead Free, Reach Compliant

3. Competitive Price and Short Lead-time

4. Professional Team with Rich Experiences in Design/Mfg/Quality Control

5. Small MOQ Support & Fast Response to Customers

6. Long Product Life Time

Details Pictures for CPT CLAA070WP03XG

CPT CLAA070WP03XG 7 inch tft lcd display , industrial display solutions

CPT CLAA070WP03XG 7 inch tft lcd display , industrial display solutions
