Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling
Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling
Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling
Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling
Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling
Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling
Specifications
Brand Name :
Speedy Laser
Model Number :
SL-FM 60W
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100 sets / month
Delivery Time :
5-7 days
Packaging Details :
Plywood packing
name :
laser machine for jewelry
laser power :
60W
working size :
110*110mm
laser wavelength :
1064nm
Laser source :
JPT laser
Description

Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling

Product Features:


JPT MOPA 60W laser power, the machine can marking / cutting 0.5mm gold silver etc.

China Raycus iber laser source, without any adjustment collimating optical element.


Smaller output laser beam ,fine marking line. Suitable high precision marking.

Using environment is liberal, Long life, laser generator life over 100,000 hours.

The machine equip special rotary for marking rings bracelet.


Application:


SL-FM 60W fiber laser marking machine wide range application,mainly for all kinds of metal jewelry such

as cutting marking gold,silver,brass, max can cut 1.5mm.The machine can engraving different english

letters, pattern,photo on the jewelry.


Technical parameters:

Item Name Technical Parameter
Model SL-FM 60W
Laser Power 60W
Laser wavelength 1064nm
Laser type JPT fiber laser source
Beam diameter 7mm±1
Repeat frequency 1KHz-4000KHz
Pulse width 2-500ns
Marking depth 0.01-1mm
Marking area 110×110mm
Rated power consumption 800W
Operating voltage 110V- 240V/50-60 Hz/15A
Cooling Air Cooling
Packing size 88*42*83cm (L*W*H)
Gross weight 60 KG
Package Standard export wooden


Jewelry cutting / marking samples:

Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling

Metal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air CoolingMetal Jewelry Laser Machine JPT 50W 60W 100W laser cutting engraving laser With Air Cooling
