Specifications
Brand Name :
BJPFM
Model Number :
PFM-Dutch Mesh
Certification :
SGS
Place of Origin :
China
MOQ :
30M
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram,PayPal
Supply Ability :
11000m/Month
Delivery Time :
5-8days after payment
Packaging Details :
Wooden case
Product name :
3um 5 Micron SS316L Stainless Steel Twill Weave Dutch Filter Wire Mesh
Material :
stainless steel,316L
Color :
Silver
Application :
Kinds Filtration Industry,filtration
Usage :
Liquid Filter
Weave style :
Plain/twill/dutch weave
Mesh count :
20-2800 mesh per inch
Technique :
Woven Wire Mesh
Business type :
factory
Description

3um 5 Micron SS316L Stainless Steel Twill Weave Dutch Filter Wire Mesh

1. 316L SS Twill Dutch Filter Mesh Description


Stainless steel dutch net mesh has different warp and weft diameters and mesh numbers
Reasonable combination of the mesh and warp to achieve a square mesh can not reach the filtering density
Therefore, the dutch weave filter mesh is a fine dutch mesh, but generally the warp diameter is larger than the weft diameter
Reverse mesh weaving is called contrast because the weft is much thicker than the warp


SS 316L Twill Weave Industrial Filter For Mining / Chemical / Food Industry

SS 316L Twill Weave Industrial Filter For Mining / Chemical / Food Industry

2. 316L SS Twill Dutch Filter Mesh Features


Stainless steel dutch mesh material: stainless steel wire , nickel wire , black wire
Weaving method: plain weave stainless steel dense pattern net (plain dutch weave), twill weave stainless steel dense pattern net (twill dutch weave), bamboo flower weave stainless steel dense pattern mesh , 316l reverse dutch mesh weave stainless steel dense pattern mesh
Performance it has the characteristics of stable filtering performance and fine filtering mesh

3. 316L SS Twill Dutch Filter Mesh Specification


Stainless Steel Dutch Woven Mesh

Weave Type

Mesh Count

Warp Wire
(Inch)

Weft Wire
(Inch)

Absolute Rating
(Micron)

Nominal Rating
(Micron)

Weight
per 100 sq.'

PDW

8x20

0.014

0.0126

330-350

280

49

PDW

12x64

0.024

0.0165

270-290

200

84

PDW

14x88

0.02

0.013

220-240

150

75

PDW

16x80

0.0196

0.0134

225-235

140

79

PDW

24x110

0.015

0.01

115-125

80

55

PDW -

24x128

2 x .010

0.004

110-120

75

34

PDW

30x150

0.009

0.007

110-112

63

33

PDW -

30x150

2 x .009

.007"

95-113

60

33

PDW

40x200

0.007

0.0055

70-75

55

27

PDW

50x250

0.0055

0.0045

58-63

40

22

PDW

80x400

0.005

0.003

40-45

35

17

TDW

30x250

0.01

0.008

110-120

53

66

TDW

80x700

0.004

0.003

35-40

25

25

TDW

120x400

0.004

0.0025

50-55

40

15

TDW

165x800

0.0028

0.002

25-28

15

14

TDW

200x600

0.0024

0.0018

30

20

10

TDW

165x1400

0.0028

0.0016

16-20

10

14

TDW

200x1400

0.0028

0.0016

12-14

5

15

TDW

325x2300

0.0014

0.001

8-9

2

10

TDW

400x2800

0.001

0.0008

6-7

1

8

4. 316L SS Twill Dutch Filter Mesh Application


Stainless steel filter screen dutch mesh is heat-resistant , acid resistant , corrosion-resistant and wear-resistant

Because of these characteristics , stainless steel dutch mesh is widely used in mining , chemical , food , petroleum, medicine and other industries , mainly used for gas , liquid filtration and other media separation
