MS1H4 Series Small Power Servo Motor INOVANCE MS1H4,MS1H4-20B30CB-T331R,SV630N/SV660N,0.2kW,3PH AC220V±15%,3000rpm,7000rpm,0.64Nm,1.92Nm
MS1H4 Series Small Power Servo Motor INOVANCE MS1H4,MS1H4-20B30CB-T331R,SV630N/SV660N,0.2kW,3PH AC220V±15%,3000rpm,7000rpm,0.64Nm,1.92Nm
Specifications
Packaging Details :
pieces
Applicationindustry :
Manufacturing, Process Control, Robotics
Part No :
CS1G-CPU43H
Ac Voltage :
208-230 / 240 V,220/380V,60V,AC220V
Output Points :
20
Supply Ability :
10PCS 1WEEK
Feedback Type :
Encoder, Resolver, Hall sensors
Brightness :
NO
Payment Terms :
T/T
Certification :
CO
Communicationprotocol :
Modbus, Profibus, Ethernet/IP
Mounting Type :
DIN rail, Panel mount
Compatibility :
SCADA Systems, HMI Panels
Model Number :
MS1H4-20B30CB-T331R
Operating Temperature :
0-40°C
Price :
Negotiable
Responsefrequency :
0-2000Hz
Response Time :
<1ms
Place of Origin :
China
Delivery Time :
1WEEK
Point :
14 (8DI+6DO)
Brand Name :
INOVANCE
Communication Interface :
RS485
MOQ :
1pcs
Output Method :
Transistor
Description
Product Specifications
Brand Product Series Motor Model Matched Driver Rated Power Rated Voltage Rated Speed Max Speed Rated Torque Max Torque Encoder Type Encoder Resolution Protection Class Insulation Class Cooling Method Key Features Net Weight
Inovance MS1H1 MS1H1-05C30CB-T331R SV630P/SV630N/SV660N 0.1kW 1PH AC220V±15% 3000rpm 7000rpm 0.32Nm 0.96Nm Incremental 20-bit IP65 Class F Natural Cooling Low Inertia; 3x Overload; Cost-effective 0.35kg
Inovance MS1H1 MS1H1-10C30CB-T331R SV630P/SV630N/SV660N 0.2kW 1PH AC220V±15% 3000rpm 7000rpm 0.64Nm 1.92Nm Incremental 20-bit IP65 Class F Natural Cooling High Response; 0.1ms Dynamic Time 0.42kg
Inovance MS1H1 MS1H1-20C30CB-T331R SV630P/SV630N/SV660N 0.4kW 1PH AC220V±15% 3000rpm 7000rpm 1.27Nm 3.81Nm Incremental 20-bit IP65 Class F Natural Cooling Double PG Closed Loop 0.58kg
Inovance MS1H1 MS1H1-40C30CB-T331R SV630P/SV630N/SV660N 0.75kW 1PH AC220V±15% 3000rpm 7000rpm 2.39Nm 7.17Nm Incremental 20-bit IP65 Class F Forced Air Cooling GB30253-1 Energy Efficiency 0.85kg
Inovance MS1H2 MS1H2-50C30CB-T331R SV630P/SV630N/SV660N 1.0kW 3PH AC220V±15% 3000rpm 6000rpm 3.18Nm 9.54Nm Incremental 20-bit IP65 Class F Forced Air Cooling Medium Inertia; Low Vibration 1.2kg
Inovance MS1H2 MS1H2-75C30CB-T331R SV630P/SV630N/SV660N 1.5kW 3PH AC220V±15% 3000rpm 6000rpm 4.77Nm 14.31Nm Incremental 20-bit IP65 Class F Forced Air Cooling High Rigidity (36 Level) 1.8kg
Inovance MS1H2 MS1H2-10C30CB-T331R SV630N/SV660N 2.0kW 3PH AC220V±15% 3000rpm 6000rpm 6.37Nm 19.11Nm Incremental 20-bit IP65 Class F Forced Air Cooling External Brake Resistor Port 2.5kg
Inovance MS1H4 MS1H4-20B30CB-T331R SV630N/SV660N 0.2kW 3PH AC220V±15% 3000rpm 7000rpm 0.64Nm 1.92Nm Incremental 20-bit IP67 Class F Natural Cooling 40mm Frame; Ultra-compact 0.45kg
Inovance MS1H4 MS1H4-40B30CB-T331R SV630N/SV660N 0.4kW 3PH AC220V±15% 3000rpm 7000rpm 1.27Nm 3.81Nm Incremental 20-bit IP67 Class F Natural Cooling High Precision Positioning; T331R Encoder 0.62kg
Inovance MS1H4 MS1H4-75B30CB-T331R SV630N/SV660N 0.75kW 3PH AC220V±15% 3000rpm 7000rpm 2.39Nm 7.17Nm Incremental 20-bit IP67 Class F Forced Air Cooling 7000rpm High Speed 0.98kg
Inovance MS1H4 MS1H4-10B30CB-T331R SV660N/SV660ND 1.0kW 3PH AC380V±15% 3000rpm 6000rpm 3.18Nm 9.54Nm Absolute 23-bit IP67 Class F Forced Air Cooling EtherCAT Sync; 15ns Error 1.5kg
