HCS02.1E-WO054-A-03-NNNN Rexroth IndraDrive C Series 54A Peak Current Built In Brake Chopper
HCS02.1E-WO054-A-03-NNNN Rexroth IndraDrive C Series 54A Peak Current Built In Brake Chopper
HCS02.1E-WO054-A-03-NNNN Rexroth IndraDrive C Series 54A Peak Current Built In Brake Chopper
HCS02.1E-WO054-A-03-NNNN Rexroth IndraDrive C Series 54A Peak Current Built In Brake Chopper
Specifications
Brand Name :
Rexroth
Certification :
Brand new original
MOQ :
1 pcs
Model Number :
HCS02.1E-WO054-A-03-NNNN
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 pcs
Delivery Time :
5-7 days
Description
HCS02.1E-WO054-A-03-NNNN Rexroth Drives
High-performance industrial drive system designed for precision motion control applications in demanding manufacturing environments.
Electrical Specifications
Parameter Specification
Main Power Supply Three-phase 200–500 V AC (±10%), 50/60 Hz
Control Power Supply 24 V DC (±20%)
Input Continuous Current 20 A
Switching Frequency Up to 8 kHz
DC Bus Supports common DC bus with energy feedback
Brake Chopper Built-in, maximum braking power 18 kW
Overload Capacity 2.5 times rated current (short time)
Input Fuse 25 A
Short Circuit Current Rating (SCCR) 42,000 A rms
Power Consumption 270 W (continuous current condition)
Model Code Analysis
HCS02.1E-W0054-A-03-NNNN
  • HCS02: IndraDrive C Series (Overseas Version)
  • 1E: Hardware Version
  • W0054: Peak Current 54 A (Continuous 20.6 A)
  • A: Control Unit Type (Basic Version)
  • 03: Design Version
  • NNNN: No additional communication/safety/I/O expansion (basic configuration)
Core Functions and Interfaces
Communication Interface
No built-in fieldbus; requires expansion slots to add Multi-Ethernet (PROFINET/EtherNet/IP/Modbus TCP), CANopen, Profibus DP, and other protocols.
Encoder Interface
Supports Hiperface, EnDat 2.1/2.2, BiSS, SSI, Resolver, TTL, and other encoder protocols.
Safety Functions
No built-in safety functions (STO/SS1); requires expansion via safety modules for comprehensive safety integration.
I/O and Operation
  • Standard digital I/O and analog interfaces
  • Built-in operation panel with 4 keys and digital display
  • Supports IndraWorks software for debugging and parameter configuration
Environmental Specifications
Parameter Specification
Operating Temperature 0°C to +40°C
Storage Temperature -25°C to +70°C
Altitude ≤ 1000 m (higher capacity requires derating)
Installation Spacing ≥50 mm ventilation space required between drives
Pollution Level Level 2 (suitable for moderately polluted industrial environments)
