Specifications
Brand Name :
EDL
Model Number :
664P-76
Certification :
ISO9001, ISO14001, RoHS
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
30,000pcs/day
Delivery Time :
3-15days
Packaging Details :
Carton
Wheel Diameter :
4inch(100mm)
Dynamic Load :
250kg
Tread Material :
TPU
Core Material :
PP
Mounting Type :
Rigid/Swivel/Brake
Mounting Height :
138mm
Frame Material :
Hot-Rolled Plate
Surface Treatment :
Zinc Coating
Plate Thickness :
4mm
Bracket Thickness :
3mm
Bracket Width :
46mm
Wheel width :
38mm
Bearing :
Double ball bearing
Tread Color :
Grey
Applicable Temperature :
-20℃～80℃
Tread Hardness :
95A
Name :
Industrial Caster Wheels
Description

EDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kg 664P-76


The EDL Medium Duty 4-inch TPU Plate Caster 664P-76 is designed for high-performance durability, supporting up to 250kg with smooth and stable mobility. The gray TPU wheel provides excellent wear resistance, shock absorption, and floor protection, making it ideal for industrial, medical, and commercial applications. With a wide operating temperature range of -20°C to 80°C, this caster maintains consistent performance in various environments. The 4mm thick reinforced plate mounting ensures strong load support and long-lasting reliability. Equipped with a high-precision dual-bearing system, it enables effortless movement and reduced rolling resistance, even under heavy loads. The dual brake and side brake options provide secure locking and enhanced stability, ensuring safety during use. Whether for warehouse trolleys, medical carts, or heavy-duty equipment, this caster combines strength, quiet operation, and easy maneuverability for demanding applications.

Wheel ltem No.Instruction

Wheel

Item No.

 Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

 Core Tread Bearing

Applicable

Temperature

 Hardness
664-76 4" 100mm 38mm 46mm 250Kg PP

TPU

Double ball

bearing 6201

 -20℃～80℃ 95A

EDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kgEDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kg

EDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kgEDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kg

EDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kgEDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kgEDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kgEDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kg

EDL‌ Medium Duty 4inch Caster TPU Plate by Rigid , Swivel and Brake Type 250kg

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.
