Specifications
Brand Name :
AIRSUSTECH
Model Number :
1B7070
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, Paypal or Others
Supply Ability :
1000PCS/Week
Delivery Time :
5-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Brand :
AIRSUSTECH
Structure :
Single Convoluted
Air Hole :
1/4 NPT
Working Stroke :
2.50 Inches
Max. Rubber Bellow :
6.50 Inches
Cross References :
Festo EB-165-65
Firestone :
W01-M58-6155
Description

Contitech FS 70-7 Air Shock Suspension Alternative AIRSUSTECH 1B7070 from China

1B7070 Air Springs Datas

Cover Plate
Top Cover Plate Diameter 4.25 inches
Screw Center Distance of Top Cover Plate 1.75 inches
Bottom Cover Plate Diameter 4.25 inches
Screw Center Distance of Bottom Cover Plate 1.75 inches
Nut/Blind Nuts
Top Cover Plate Screw(Nut) Tooth 2×3/8UNC
Bottom Cover Plate Screw(Nut) Tooth 2×3/8UNC
Gas Hole/Air Inlet/Air Fitting
Air Hole 1/4NPT
Rubber Bellow
Rubber Bellow Max. Diameter 8.50 inches
Installation Space 7.09 inches
Minimum Height 2.00 inches
Maximum Height 4.50 inches

OEM Cross References

Contitech FS 70-7

Contitech FS70-7

Contitech FS 707

Contitech FS707
Phoenix SP 1B 05

Phoenix SP 1B05

Phoenix SP1B05
Bosch 8224 19002

Bosch 822419002
Festo EB-165-65

Festo EB16565

Festo EB 165 65
Weforma WBE 200-E1

Weforma WBE 200E1

Weforma WBE200-E1

Weforma WBE 200 E1
Firestone W01-M58-6155

Firestone W01M586155

Firestone W01 M58 6155

Rubber Damage from Chemicals


Grease and oil are common examples that can cause this condition after prolonged contact with the rubber flexible member.

  1. Excessive oil in the air supply.
  2. Excessive greasing of universal joints.
  3. Excessive greasing of the fifth wheel.
  4. Leaking seals in suspension components.
  5. Use of petroleum based cleaners on the air spring (use only soap and water for cleaning)

We Offer Other Convoluted Air Springs

Single Convoluted Double Convoluted Triple Convoluted
FS 40-6 CI FD 40-10 CI FT 330-29 CI
FS 50-5 CI FD 70-13 CI FT 430-32 CI
FS 70-7 CI FD 110-15 CI FT 530-32 CI
FS 100-10 CI FD 120-17 CI FT 530-35 CI
FS 120-10 CI FD 120-20 CI FT 960-34 CI
FS 120-12 CI FD 200-19 CI FT 1330-35 CI
FS 200-10 CI FD 200-22 CI
FS 310-12 CI FD 200-25 CI
FS 330-11 CI FD 330-22 CI
FS 330-14 CI FD 330-30 CI
FS 530-11 CI FD 530-22 CI
FS 530-14 CI FD 530-35 CI
FS 960-12 CI FD 960-22 CI
FS 1330-11 CI FD 1330-25 CI
