12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
Specifications
Brand Name :
AIRSUSTECH
Model Number :
12X2P05
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou, China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T,Western Union,Paypal or Others,L/C,D/A,D/P,MoneyGram
Supply Ability :
1000 PCS/Week
Delivery Time :
3-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Warranty :
12 Months
Model No. :
12X2P05
Mounting Holes :
12-M8
Bellows Type :
Double Convoluted
Size :
12''
Max. Lifting Pressure :
7 Bar
Durability :
High
Operation :
Gas-filled
Description
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
Product Specifications
Specification Value
Flange Ring Diameter 245 mm
PCD 230 mm
Threaded Holes 12-M8
Natural Diameter 301 mm
Design Height 164 mm
Inner Opening Diameter 176 mm
Outer Opening Diameter 210 mm
Product Applications
  • Gate Valve Operator
  • Glue Coating Machine
  • Web Tightening Tool
  • Stripper
  • Tool Spring Driver
  • Quenching Drain Driver
  • Paper Mill
  • Pickling Tank Driver
Flange Air Springs: Versatile Solutions for Shock Absorption and Vibration Isolation

Industrial Applications: In industrial equipment, flange air springs serve as effective shock absorbers and vibration isolators for various machinery, instruments, and meters. They help reduce operational vibrations, enhance equipment stability, and improve overall work efficiency.

Transportation Applications: Flange air springs are widely utilized in automotive suspension systems and railway vehicle vibration reduction devices. They minimize bumps and vibrations during driving, providing improved ride comfort and enhanced safety for passengers.

Construction Applications: In construction, flange air springs are applied for seismic isolation and vibration control in large buildings. They reduce the impact of earthquakes, helping protect both property and personal safety.

Other Air Bellows with Flange Rings
Dunlop Firestone
4 1/2 X 1 W01-R58-4043
4 1/2 X 2 W01-R58-4076
6 X 2 W01-R58-4036
8 X 1 W01-R58-4085
8 X 2 W01-R58-4045
10 X 2 W01-R58-4048
10 X 3 W01-R58-4047
12 X 2 W01-R58-4044
12 X 3 W01-R58-4046
16 X 2 W01-R58-4023
Product Images
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
12X2P05 Flange Connection Air Spring Customization PCD 230 MM for Reduce Vibration
