Specifications
Brand Name :
AIRSUSTECH
Model Number :
1B130070
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou, China
MOQ :
1 pieces
Price :
Negotiable
Payment Terms :
T/T,,Paypal or Others,L/C,D/A,D/P,MoneyGram
Supply Ability :
1000pcs/week
Delivery Time :
3-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Supplier :
AIRSUSTECH
Part Number :
1B130070
Stroke :
41 MM
Port Size :
1/4BSP
Material :
Rubber and Steel Plate
Firestone :
W01-358-7001
Manufacturer Warranty :
One Year
Max Inflation Pressure :
7 Bar
Description
Single Convoluted Bellows W01-358-0017 Firestone Industrial Air Spring from China
Single Convoluted Bellows W01-358-0017 Firestone Industrial Air Spring from China
Quick Details
Types of Goods Industrial Air Springs
Sample Available
Function Reduce Shock
Condition Brand New
MOQ 1 Piece
HS Code 870880
Quality High Quality
The Technical Datas of AIRSUSTECH 1B130070
  • Minimum usable height: 48 mm
  • Maximum usable height: 89 mm
  • Center distance: 44 mm
  • Cover plate width: 114 mm
  • Threaded hole: 2×M8×1.25
  • Port size: 1/4 BSP
  • Max. usable diameter: 152 mm
Dynamic Characteristics at 75 mm Design Height
Gauge Pressure (BAR) Load (kN) Spring Rate (kN/m) Natural Frequency (Hz)
3 2.04 140 4.13
4 2.76 177 3.99
5 3.52 217 3.91
6 4.36 256 3.82
7 5.10 293 3.78
Force Table
Assembly Height (mm) Volume @ 100 BAR (cu cm) EFF Area @ 7 BAR (cu sq) kN Force @ 3 BAR kN Force @ 4 BAR kN Force @ 5 BAR kN Force @ 6 BAR kN Force @ 7 BAR
80 575 61 1.61 2.25 2.89 3.62 4.26
70 492 83 2.37 3.20 4.06 4.98 5.81
60 39.0 99 2.85 3.88 4.89 5.95 6.93
Firestone Style 16 Metric M8 Air Spring Numbers
Blind nuts, 1/4 BSP W01-M58-6140, W01M586140, W01 M58 6140 WO1-M58-6140, WO1M586140, WO1 M58 6140
Socket head aluminum bead rings (bolts, nuts, washers not included-use M6 cap screws) W01-358-0017, W013580017, W01 358 0017 WO1-358-0017, WO13580017, WO1 358 0017
Rubber bellows only W01-358-0010, W013580010, W01 358 0010 WO1-358-0010, WO13580010, WO1 358 0010
Firestone Style 16 Imperial 3/8-16 UNC Air Spring Numbers
Blind nuts, 1/4NPT W01-358-7001, W013587001, W01 358 7001 WO1-358-7001, WO13587001, WO1 358 7001
Blind nuts, 3/4NPT W01-358-6996, W013586996, W01 358 6996 WO1-358-6996, WO13586996, WO1 358 6996
Socket head aluminum bead rings (bolts, nuts, washers not included-use 1/4 cap screws) W01-358-0017, W013580017, W01 358 0017 WO1-358-0017, WO13580017, WO1 358 0017
3/4NPT (only) upper plate, blind nuts lower plate W01-358-0286, W013580286, W01 358 0286 WO1-358-0286, WO13580286, WO1 358 0286
Rubber bellows only W01-358-0010, W013580010, W01 358 0010 WO1-358-0010, WO13580010, WO1 358 0010
Related Images of 1B130070 Air Actuator
Single Convoluted Bellows W01-358-0017 Firestone Industrial Air Spring from China
Single Convoluted Bellows W01-358-0017 Firestone Industrial Air Spring from China
Factory Workshop
Single Convoluted Bellows W01-358-0017 Firestone Industrial Air Spring from China
AIRSUSTECH manufacturing facility
Single Convoluted Bellows W01-358-0017 Firestone Industrial Air Spring from China
Quality control inspection of air springs
