Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
Specifications
Coolingsystem :
Water-cooled
Material :
Stainless steel
Color :
Support cutomized
Meltingtemperature :
1600°C
Rated Temperature :
1800℃
Delivery Time :
15 working days
Brand Name :
Lanshuo
Dc Voltage :
990V Phase
Certification :
CE
Price :
24,000-28,000 usd /set
Model Number :
KGPS-1400
MOQ :
1 set
Supply Ability :
300 set per year
MOQ :
1 SET
Payment Terms :
T/T, L/C, Western Union
Capacity :
2000 kg
Medium Voltage :
750v Phase
Packaging Details :
Pallet+wooden case
Feature :
Power Saving
Voltage :
380V
Work Condiction :
24hours
Place of Origin :
Henan, China
Power Source :
electricity
Key Selling Points :
Long Service Life
If Frequency :
500HZ
Application :
Industrial
Controlsystem :
Hydraulic
Place of origin :
Zhengzhou, Henan province
Core components :
Main control board
Description

Introduction:

Intermediate Frequency Melting Furnace: Designed for smelting ferrous & non-ferrous metals and their alloys including steel and copper, widely used in foundry and steelmaking sectors.

Product Advantages:

High Efficiency: Rapid smelting cycle, a full furnace can be fully melted within 40 minutes at minimum.

Energy Saving: Superior energy efficiency: power consumption hits approx. 510 kWh/ton of cast iron, around 20% lower power consumption vs conventional parallel inverter power sources.

Quality: All units are certified to ISO quality management standards and EU CE safety directives.

Performance Features

High-efficiency series-type power solution in 1-drive-2 or 1-drive-multiple configuration: several furnaces for smelting while one for molten metal holding. This series of intermediate frequency power supplies supports single, dual or multi-output layout. This new 1-drive-multi series IF furnace allows one single power unit to drive two or more furnace bodies running concurrently. It facilitates one-shot pouring for heavy castings and continuous molten iron feeding to automated foundry lines.

Advanced computer melting management system: Our on-site smelting management platform consists of industrial PC, digital main control board and PLC into an integrated network, extendable via network switch for remote office supervision. Built-in Ethernet, USB interfaces and exclusive static IP enable global remote data acquisition, real-time monitoring, online diagnosis and fast fault elimination.

Fully digital on-site melting control system: Fully digital control system supports auto constant-temperature maintenance, auto furnace preheating, real-time power split display, intelligent smelting scheduling, fault code display & data logging and other automatic control functions.

Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use

Steel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial UseSteel Melting Induction Electric Furnace 2 Ton New Type Conductive Induction Heating for Industrial Use
