Chassis configuration: wheelbase 1995+4500+1350, driver's cab D320 semi standard roof, engine DDi75E350-60, rear processing box type, transmission 9JS135TA, gear ratio 11.02/0.73, front and rear axles 5.5T10T single reduction, leaf spring 3/3/-/-, frame 300 × 90 × 8+4, fuel tank aluminum 350L, main reduction ratio 4.44, tires 295/80R22.5 18PR, with side power take-off and air conditioning, PTO interface, no PTO device, with dash cam interface, exhaust pipe front, front disc brake, front tire burst emergency, ECU speed limit, dangerous goods warning light, EBS (electric air brake system), FC. WS/LDWS (Forward Collision/Lane Departure Warning), TPMS (Front Axle Single Tire Pressure Monitoring), ESC (Anti rollover System), engine brake+exhaust brake
Upper configuration: The effective volume of the tank body is 24.8 cubic meters (Yunnan standard diesel gasoline tank) or 25.5 cubic meters (diesel gasoline tank), 30 cubic meters (gasoline tank), made of 5182 aluminum alloy plate, with 6 thick tanks, 6 thick heads, and 6 thick partitions. It has a single compartment, two European standard tank ports on the top of the tank, 1 new intelligent shut-off valve, 1 set of lower oil loading (unloading valve, oil vapor recovery, anti overflow probe, anti-static reel), equipped with an 80-60 special oil pump (can pump in and out). The rear ladder, manual guardrail, toolbox, rear bumper, and side guardrail are all made of aluminum alloy plate, made according to the new standard. Other manufacturers come standard with tank body inspection reports. Provide chassis certificate, vehicle certificate, and household invoice.
Precautions for refueling trucks:
(1) Check if the rear anti-static traction belt is on the ground and if all equipment is functioning properly.
(2) Insert the pole into the damp ground to prevent static electricity from catching fire.
(3) Check whether the clutch control handle, power take-off control handle, and control valve switch are in the correct position, whether the throttle is turned to the minimum, and whether the ball valve handles are in the correct position.
(4) Check the lubricating oil level in the pump gearbox. If it is insufficient, add gear oil.
(5) When there is no liquid in the oil pump, a guide fluid should be added to the pump body in advance. When using a new car for the first time, it is necessary to add a guide fluid to the pump to prevent damage to the pump body caused by dry running without liquid.
(6) Check whether the discharge pipeline, discharge valve, and conveying pipe are empty and clean, ensuring that all pipelines are suitable for loading and unloading medium items.
(7) If liquid needs to be extracted, the rotating equipment should be kept away from the oil tanker to prevent entanglement. When extracting liquid, the pump should be stopped promptly and the valve should be closed.
(8) In emergency situations, the emergency control valve should be promptly closed and cut off.
FAQ
1.Q:Are you a factory or a trade company?
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts.  Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
  A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?

A:Yes.  We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?

A:We can provide various certifications associate.  Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?

A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?

A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?

A:We provide lifelong tracking service and one year free warranty for all of our products.  Meanwhile we provide free training and technical support to guide you repair your product.  If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
