DC EMI Filter Chassis Mount CUI VFM-25C 25 Amp 0 to 36 Volt Input Voltage Noise Reduction Component
DC EMI Filter Chassis Mount CUI VFM-25C 25 Amp 0 to 36 Volt Input Voltage Noise Reduction Component
DC EMI Filter Chassis Mount CUI VFM-25C 25 Amp 0 to 36 Volt Input Voltage Noise Reduction Component
DC EMI Filter Chassis Mount CUI VFM-25C 25 Amp 0 to 36 Volt Input Voltage Noise Reduction Component
DC EMI Filter Chassis Mount CUI VFM-25C 25 Amp 0 to 36 Volt Input Voltage Noise Reduction Component
DC EMI Filter Chassis Mount CUI VFM-25C 25 Amp 0 to 36 Volt Input Voltage Noise Reduction Component
Specifications
Filter Type :
DC Filter
Voltage - Input :
36V
Current Rating :
25A
Mounting Type :
Base Mount
Description :
DC Filter Base Mount Power Line Filter Modules RoHS
Mfr. Part # :
VFM-25C
Model Number :
VFM-25C
Description

Product Overview

The CUI VFM-XX Series is a range of DC EMI Filters designed to reduce common and differential mode noise. These filters are suitable for use with a wide range of DC/DC converters, offering a compact size and effective noise suppression for various DC power applications. They are ideal for applications requiring compliance with conducted emissions standards.

Product Attributes

  • Brand: CUI
  • Warranty: 2 Year Limited

Technical Specifications

Part NumberMounting StyleInput Voltage Range (Vdc)Input Surge Voltage (Vdc)Input Current Max (A)Isolation Voltage (Vdc)Dimensions (mm)Case Material
VFM-10ABoard Mount0 ~ 75100101,50050.8 x 25.4 x 11.7Black Plastic
VFM-15CChassis Mount0 ~ 75100151,500103.2 x 79 x 22.7Black Coated Steel
VFM-20ABoard Mount0 ~ 75100201,50050.8 x 40.6 x 12.7Black Plastic
VFM-25CChassis Mount0 ~ 3650251,500103.2 x 79 x 22.7Black Coated Steel
ParameterConditions/DescriptionMinNomMaxUnits
Isolation VoltageInput to ground, output to ground1,500Vdc
Isolation ResistanceInput to ground, output to ground107W
DC ResistanceTotal for two legs16mW
Operating Temperature-40100C
Case Temperature100C
Storage Temperature-40100C

2411192357_CUI-VFM-25C_C6913895.pdf
