Specifications
Filter Type :
DC Filter
Voltage - Input :
80V
Current Rating :
3A
Mounting Type :
Base Mount
Description :
DC Filter Base Mount Power Line Filter Modules RoHS
Mfr. Part # :
VFM-03-T
Model Number :
VFM-03-T
Description

CUI VFM-03 DC Power Line Filter

The CUI VFM-03 series is a DC power line filter designed to reduce EMI noise on DC power lines. It offers frequency attenuation up to 20 dB and is available in DIP, chassis, and DIN rail mounting options, making it optimized for various integration needs. This filter is suitable for applications requiring reliable DC power conditioning.

Product Attributes

  • Brand: CUI Inc
  • Certifications: RoHS

Technical Specifications

ParameterConditions/DescriptionMinTypMaxUnits
Input Voltage080Vdc
Input CurrentMaximum filter3A
Noise Attenuationat 150 kHz ~ 1 GHz20dB
Isolation Voltage1,500Vdc
Operating Temperature-4085C
Storage Temperature-55125C
Storage Humiditynon-condensing595%
Case Temperature Riseat nominal current40C
Solderability (Hand Soldering)for 3~5 seconds350360370C
Solderability (Wave Soldering)see wave soldering profile260C
Dimensions (Board Mount)25.40 x 25.40 x 11.70 [1.000 x 1.000 x 0.461]mm [inch]
Dimensions (Chassis Mount)76.00 x 31.50 x 21.20 [2.992 x 1.240 x 0.835]mm [inch]
Dimensions (DIN-Rail Mount)76.00 x 31.50 x 25.80 [2.992 x 1.240 x 1.016]mm [inch]
Weight (Board Mount)15g
Weight (Chassis Mount)35g
Weight (DIN-rail Mount)55g
