Plastic Can Motor Run Capacitor KEMET C276CCF4550LG0J Polypropylene Film Self Healing Dielectric
Plastic Can Motor Run Capacitor KEMET C276CCF4550LG0J Polypropylene Film Self Healing Dielectric
Plastic Can Motor Run Capacitor KEMET C276CCF4550LG0J Polypropylene Film Self Healing Dielectric
Plastic Can Motor Run Capacitor KEMET C276CCF4550LG0J Polypropylene Film Self Healing Dielectric
Plastic Can Motor Run Capacitor KEMET C276CCF4550LG0J Polypropylene Film Self Healing Dielectric
Plastic Can Motor Run Capacitor KEMET C276CCF4550LG0J Polypropylene Film Self Healing Dielectric
Specifications
Capacitance :
5.5uF
Operating Temperature :
-25℃~+85℃
Tolerance :
±5%
Voltage Rating :
470V
Description :
5.5uF -25℃~+85℃ ±5% 470V Motor Start, Motor Run Capacitors (AC) RoHS
Mfr. Part # :
C276CCF4550LG0J
Model Number :
C276CCF4550LG0J
Description

KEMET C27 Motor Run Capacitors

The KEMET C27 is a cylindrical, plastic can-type metallized polypropylene film capacitor designed for motor run applications. It features a self-healing dielectric, IMQ and UL810 approved construction, and is rated for 50 Hz and 60 Hz frequencies. Offering high capacitance density, it is suitable for motor run applications within safety class S0.

Product Attributes

  • Brand: KEMET
  • Origin: USA
  • Material: Polypropylene film, plastic can (Noryl for diameters > 50 mm), Polyurethane filling resin
  • Certifications: IMQ and UL810 approved (construction only)
  • Safety Class: S0

Technical Specifications

Part Number Series Capacitance (F) Rated Voltage (VAC) Tolerance Terminal Style Dimensions (D x H mm) dV/dt (V/s) Operating Class Packaging Quantity
C274AC24100AA0J C27/4 1 470 5% Single faston 25 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC24125AA0J C27/4 1.25 470 5% Single faston 25 x 58 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC24150AA0J C27/4 1.5 470 5% Single faston 25 x 58 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC24200AA0J C27/4 2 470 5% Single faston 25 x 58 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC24250AA0J C27/4 2.5 470 5% Single faston 25 x 58 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC24300AA0J C27/4 3 470 5% Single faston 25 x 58 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC24400AA0J C27/4 4 470 5% Single faston 30 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 110
C274AC24500AA0J C27/4 5 470 5% Single faston 30 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 110
C274AC24600AA0J C27/4 6 470 5% Single faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC24630AA0J C27/4 6.3 470 5% Single faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC24700AA0J C27/4 7 470 5% Single faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC24750AA0J C27/4 7.5 470 5% Single faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC24800AA0J C27/4 8 470 5% Single faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC25100AA0J C27/4 10 470 5% Single faston 35 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC25120AA0J C27/4 12 470 5% Single faston 35 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC25125AA0J C27/4 12.5 470 5% Single faston 35 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC25160AA0J C27/4 16 470 5% Single faston 40 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 60
C274AC25250AA0J C27/4 25 470 5% Single faston 45 x 93 20 Class A (30,000 hrs @ 420 VAC) 50
C274AC25300AA0J C27/4 30 470 5% Single faston 45 x 93 20 Class A (30,000 hrs @ 420 VAC) 50
C274AC25315AA0J C27/4 31.5 470 5% Single faston 45 x 93 20 Class A (30,000 hrs @ 420 VAC) 50
C274AC34100AA0J C27/4 1 470 5% Double faston 25 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC34150AA0J C27/4 1.5 470 5% Double faston 25 x 58 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC34200AA0J C27/4 2 470 5% Double faston 25 x 58 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC34250AA0J C27/4 2.5 470 5% Double faston 25 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC34300AA0J C27/4 3 470 5% Double faston 25 x 58 20 Class A (30,000 hrs @ 420 VAC) 162
C274AC34400AA0J C27/4 4 470 5% Double faston 30 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 110
C274AC34500AA0J C27/4 5 470 5% Double faston 30 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 110
C274AC34600AA0J C27/4 6 470 5% Double faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC34630AA0J C27/4 6.3 470 5% Double faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC34700AA0J C27/4 7 470 5% Double faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC34750AA0J C27/4 7.5 470 5% Double faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC34800AA0J C27/4 8 470 5% Double faston 35 x 56.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC34900AA0J C27/4 9 470 5% Double faston 35 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC35100AA0J C27/4 10 470 5% Double faston 35 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC35110AA0J C27/4 11 470 5% Double faston 35 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC35120AA0J C27/4 12 470 5% Double faston 35 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC35125AA0J C27/4 12.5 470 5% Double faston 35 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274AC35140AA0J C27/4 14 470 5% Double faston 40 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 60
C274AC35150AA0J C27/4 15 470 5% Double faston 40 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 60
C274AC35160AA0J C27/4 16 470 5% Double faston 40 x 73.5 20 Class A (30,000 hrs @ 420 VAC) 60
C274AC35180AA0J C27/4 18 470 5% Double faston 45 x 74 20 Class A (30,000 hrs @ 420 VAC) 50
C274AC35200AA0J C27/4 20 470 5% Double faston 45 x 74 20 Class A (30,000 hrs @ 420 VAC) 50
C274AC35250AA0J C27/4 25 470 5% Double faston 45 x 93 20 Class A (30,000 hrs @ 420 VAC) 50
C274AC35300AA0J C27/4 30 470 5% Double faston 45 x 93 20 Class A (30,000 hrs @ 420 VAC) 50
C274AC35350AA0J C27/4 35 470 5% Double faston 50 x 95 20 Class A (30,000 hrs @ 420 VAC) 40
C274AC35400AA0J C27/4 40 470 5% Double faston 50 x 120 20 Class A (30,000 hrs @ 420 VAC) 40
C274AC35500AA0J C27/4 50 470 5% Double faston 50 x 120 20 Class A (30,000 hrs @ 420 VAC) 40
C274AC35550AA0J C27/4 55 470 5% Double faston 55 x 120 20 Class A (30,000 hrs @ 420 VAC) 32
C274AC35600AA0J C27/4 60 470 5% Double faston 55 x 121 20 Class A (30,000 hrs @ 420 VAC) 32
C274ACA4100AL0J C27/4 1 470 5% Unipolar flexible cable (tinned end) 25 x 55 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACA4150AL0J C27/4 1.5 470 5% Unipolar flexible cable (tinned end) 25 x 55 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACA4200AL0J C27/4 2 470 5% Unipolar flexible cable (tinned end) 25 x 55 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACA4250AL0J C27/4 2.5 470 5% Unipolar flexible cable (tinned end) 25 x 55 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACA4300AL0J C27/4 3 470 5% Unipolar flexible cable (tinned end) 25 x 55 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACA4400AL0J C27/4 4 470 5% Unipolar flexible cable (tinned end) 30 x 55 20 Class A (30,000 hrs @ 420 VAC) 110
C274ACA4500AL0J C27/4 5 470 5% Unipolar flexible cable (tinned end) 30 x 55 20 Class A (30,000 hrs @ 420 VAC) 110
C274ACA4600AL0J C27/4 6 470 5% Unipolar flexible cable (tinned end) 35 x 55 20 Class A (30,000 hrs @ 420 VAC) 86
C274ACF4100LF0J C27/4 1 470 5% Unsheathed bipolar cable (tinned end) 25 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACF4150LF0J C27/4 1.5 470 5% Unsheathed bipolar cable (tinned end) 25 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACF4200LF0J C27/4 2 470 5% Unsheathed bipolar cable (tinned end) 25 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACF4250LF0J C27/4 2.5 470 5% Unsheathed bipolar cable (tinned end) 25 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACF4300LF0J C27/4 3 470 5% Unsheathed bipolar cable (tinned end) 25 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 162
C274ACF4400LF0J C27/4 4 470 5% Unsheathed bipolar cable (tinned end) 30 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 110
C274ACF4500LF0J C27/4 5 470 5% Unsheathed bipolar cable (tinned end) 30 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 110
C274ACF4600LF0J C27/4 6 470 5% Unsheathed bipolar cable (tinned end) 35 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274ACF4800LF0J C27/4 8 470 5% Unsheathed bipolar cable (tinned end) 35 x 58.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274ACF5100LF0J C27/4 10 470 5% Unsheathed bipolar cable (tinned end) 35 x 71.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274ACF5120LF0J C27/4 12 470 5% Unsheathed bipolar cable (tinned end) 35 x 71.5 20 Class A (30,000 hrs @ 420 VAC) 86
C274ACF5150LF0J C27/4 15 470 5% Unsheathed bipolar cable (tinned end) 40 x 71.5 20 Class A (30,000 hrs @ 420 VAC) 60
C274ACF5200LF0J C27/4 20 470 5% Unsheathed bipolar cable (tinned end) 45 x 71.5 20 Class A (30,000 hrs @ 420 VAC) 50
C274ACF5300LF0J C27/4 30 470 5% Unsheathed bipolar cable (tinned end) 45 x 93 20 Class A (30,000 hrs @ 420 VAC) 50
C274ACF5350LF0J C27/4 35 470 5% Unsheathed bipolar cable (tinned end) 50 x 93 20 Class A (30,000 hrs @ 420 VAC) 40
C274ACF5400LF0J C27/4 40 470 5% Unsheathed bipolar cable (tinned end) 50 x 120 20 Class A (30,000 hrs @ 420 VAC) 40
C276CC24150AA0J C27/6 1.5 470 5% Single faston 25 x 58 15 Class B (10,000 hrs @ 420 VAC) 162
C276CC24200AA0J C27/6 2 470 5% Single faston 25 x 58 15 Class B (10,000 hrs @ 420 VAC) 162
C276CC24250AA0J C27/6 2.5 470 5% Single faston 25 x 58 15 Class B (10,000 hrs @ 420 VAC) 162
C276CC24300AA0J C27/6 3 470 5% Single faston 25 x 58 15 Class B (10,000 hrs @ 420 VAC) 162
C276CC24315AA0J C27/6 3.15 470 5% Single faston 25 x 58 15 Class B (10,000 hrs @ 420 VAC) 162
C276CC24400AA0J C27/6 4 470 5% Single faston 25 x 58 15 Class B (10,000 hrs @ 420 VAC) 162
