Qualcomm B39391R882H210 resonator designed for frequency control in transmitters and local oscillators
Qualcomm B39391R882H210 resonator designed for frequency control in transmitters and local oscillators
Specifications
Description :
Resonators RoHS
Mfr. Part # :
B39391R882H210
Model Number :
B39391R882H210
Description

Product Overview

The SAW Components R 882 is a 1-port resonator designed for reliable, fundamental mode, quartz frequency stabilization. It is suitable for applications such as transmitters and local oscillators. The resonator features a ceramic package with a protection layer of Elpas and nickel, gold-plated terminals.

Product Attributes

  • Brand: EPCOS AG
  • Package Type: QCC4A
  • Terminals: Ni, gold plated
  • Electrostatic Sensitive Device (ESD): Yes

Technical Specifications

ModelCenter frequency (fc)Minimum insertion attenuation (min)Unloaded quality factor (QU)Ageing of fcMotional capacitance (C1)Motional inductance (L1)Motional resistance (R1)Parallel capacitance (C0)Temperature coefficient of frequency (TCf)Turnover temperature (T0)
R 882389,900 - 390,100 MHz (typ. 390,00 MHz)1,1 - 1,5 dB8700 - 1200010/+50 ppm2,37 fF70,27 H15 - 20 2,5 pF0,032 ppm/K10 - 40 C

Maximum Ratings

ParameterSymbolValueUnit
Operable temperature rangeTA40/+125C
Storage temperature rangeTstg40/+125C
DC voltageVDC12V
Source powerPs0dBm

Pin Configuration

1: Input
3: Output, grounded in 1-port conf.
2,4: Ground (case)


2411220722_Qualcomm-B39391R882H210_C19601039.pdf
