Power supply current sensing resistor FH RBE-05UR820FT for LED lamps motor circuits and portable devices
Power supply current sensing resistor FH RBE-05UR820FT for LED lamps motor circuits and portable devices
Specifications
Power(Watts) :
125mW
Resistance :
820mΩ
Type :
Current Sense Resistor
Temperature Coefficient :
±400ppm/℃
Tolerance :
±1%
Description :
820mΩ ±1% 125mW Current Sense Resistor
Mfr. Part # :
RBE-05UR820FT
Model Number :
RBE-05UR820FT
Package :
0805
Description

Product Description

Current detecting resistors for power supply, motor circuits, LED switching power supplies, audio applications, voltage regulation modules (VRMs), DC-DC converters, chargers, LED lamps, and portable devices. RoHS compliant and halogen-free.

Product Attributes

  • Certifications: RoHS Compliant, Halogen free

Technical Specifications

TypeResistance Value RangePower RatingToleranceT.C.R. (ppm/C)Dimensions (mm)Max. Overload Current (A)Rated Voltage (V)
Current Sensing Thick Film Chip Fixed Resistor0.005 to 10001/16W to 3/4W1%, 2%, 3%, 5%100, 150, 400, 500, 700, 800, 1000, 15000402, 0603, 0805, 1206, 1210, 2010, 25121.98 to 25100 to 400
RCMY08 / RCMT08 / RCML080.002 to 2001/16W to 1W1%, 2%, 3%, 5%100, 150, 400, 500, 700, 800, 1000, 150001005, 0201, 0402, 0603, 0805, 1206, 1210, 2010, 2512N/AN/A

2410121617_FH-RBE-05UR820FT_C2936652.pdf
