High Density Packaging Surface Mount Resistor Network CTS 752091561GTR7 with Lead Free Termination Finish
High Density Packaging Surface Mount Resistor Network CTS 752091561GTR7 with Lead Free Termination Finish
High Density Packaging Surface Mount Resistor Network CTS 752091561GTR7 with Lead Free Termination Finish
High Density Packaging Surface Mount Resistor Network CTS 752091561GTR7 with Lead Free Termination Finish
High Density Packaging Surface Mount Resistor Network CTS 752091561GTR7 with Lead Free Termination Finish
High Density Packaging Surface Mount Resistor Network CTS 752091561GTR7 with Lead Free Termination Finish
Specifications
Number of Resistors :
8
Number of Pins :
9
Tolerance :
±2%
Resistance :
560Ω
Power(Watts) :
80mW
Temperature Coefficient :
±200ppm/℃
Description :
8 ±2% 560Ω 80mW ±200ppm/℃ Resistor Networks, Arrays
Mfr. Part # :
752091561GTR7
Model Number :
752091561GTR7
Description

CTS 752 Series Surface Mount Resistor Network

The CTS 752 Series Resistor Networks are single packaged devices featuring an array of homogeneous resistor elements. These networks offer a smaller circuit footprint, excellent reliability, improved TCR tracking, and resistor tolerance matching, while reducing component count for cost savings in placement. Designed for high-density packaging, they are suitable for various demanding applications.

Product Attributes

  • Brand: CTS
  • Product Type: Surface Mount Resistor Network
  • Construction: Solid Ceramic
  • Termination Finish: Nickel Barrier Solder-Coated Pads (Lead-Free)
  • Packaging: Tape and Reel
  • Certifications: RoHS Compliant in Accordance with EU Directive 2011/65/EU - Lead-Free Termination Finish - Exemption 7(c)-I

Features

  • Low Profile Surface Mount Lead-Less Package
  • High Density Packaging - Single Row [SRT] & Dual Row [DRT] Terminations
  • No Internal Dendrite Growth
  • Designed for Visual Inspection & Board Cleaning

Applications

  • Telecom Infrastructure
  • Optical Networking
  • Wireless Networks
  • Storage Area Networks
  • Media Servers
  • Test & Measurement
  • Industrial Controls
  • Medical Electronics
  • Commercial & Aerospace

Technical Specifications

Specification Details
Operating Conditions
  • Power Rating @ +25C: 1.2W (8 Pad SRT) to 2.0W (24 Pad DRT)
  • Power Rating @ +70C: 0.08W (8 Pad SRT) to 1.3W (24 Pad DRT)
  • Maximum Resistor Power (Total network power): 0.12W (SRT 8 Pad) to 2.0W (DRT 24 Pad) @ +25C; 0.08W (SRT 8 Pad) to 1.3W (DRT 24 Pad) @ +70C
  • Resistance Range: 10 ohm to 1M ohm
  • Resistance Tolerance: 2% Std. or 0.5 ohm (whichever is greater)
  • Operating Temperature Range: -55C to +125C
  • Temperature Coefficient: 200ppm/C (standard, 10 Ohms - 1M); 100ppm/C (special, 33 ohms - 1M ohms)
  • Dielectric Strength: 100VAC
  • Maximum Operating Voltage: 25V
Environmental Parameters
  • Thermal Cycle: 0.50, 5 cycles -65C to +125C
  • Short Time Overload: 0.50, 2 times rated working voltage for 5 seconds (100V maximum)
  • Moisture Resistance: 0.50, 106, 240 hours, 0.1 rated load, -10C to +65C, 90% RH
  • Load Humidity: 1.00, 1,000 hours, 0.1 rated load, +70C, 85% - 92% RH
  • High Temperature Exposure: 1.00, 240 hours @ +125C, no load
  • Load Life: 1.00, 108, Condition F, 2,000 hours @ +70C, rated load
  • Resistance to Solder Heat: 0.25, 30 seconds @ +218C, dwell
  • Mechanical Shock: 0.25, 213 Condition I, 100g, 1m second, 3 shocks each plane
  • Vibration: 0.25, 204 Condition D, 20g, 10Hz - 2,000Hz, 4 hours per plane
  • Leaching Test: No leach > 50% EIA/IS-703-4.13.B, Immerse in +245C 5C SAC305 solder pot for 30 sec.
  • Shear Test: NA, 2,000PSI
  • Low Temperature Storage: 0.25, 24 hours @ -65C, no load
  • Low Temperature Operation: 0.25, 45 minutes @ -65C, full load
  • Flammability: N/A, 94V-0
  • Non-Fungus: Pass
  • Resistance to Solvents: Pass, Isopropyl alcohol, Freon TMC
  • Solderability: Pass, RMA Flux, +230C, 5 seconds dip, 95% coverage
Mechanical Specifications
  • Package Dimensions: 11.81 0.12mm (0.465 0.005 in) for 08/16 pads up to 16.89 0.12mm (0.665 0.005 in) for 12/24 pads
  • Termination: JEDEC termination code (e3). Barrier plating is nickel [Ni] over silver [Ag] thick film pad with Matte tin [Sn] finish.
  • Reflow Conditions: Per JEDEC-J-STD-020; +260C maximum, 20 seconds.
  • MSL: 1
Part Weight
  • 08/16 Pads: 180.70mg
  • 09/18 Pads: 203.30mg
  • 10/20 Pads: 225.90mg
  • 12/24 Pads: 271.10mg
