824-2500MHz Electronic Tv Antenna / LED Light Lamps Antenna Wifi Outdoor Extender
824-2500MHz Electronic Tv Antenna / LED Light Lamps Antenna Wifi Outdoor Extender
824-2500MHz Electronic Tv Antenna / LED Light Lamps Antenna Wifi Outdoor Extender
824-2500MHz Electronic Tv Antenna / LED Light Lamps Antenna Wifi Outdoor Extender
Specifications
Brand Name :
ZD
Model Number :
ZD-LLA-825-3/7NF
Certification :
RoHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000pcs per month
Delivery Time :
Shipped in 25 days after payment
Packaging Details :
Standard Packing or as customer required
Frequency Range :
824-2500MHz
Connector :
N-Female or customized
Gain :
3-7
VSWR :
1.5
Polarization :
Vertical
Description

Antenna Factory 824-2500MHz LED light lamps wi-fi range extender satellite antenna lawn lamp

Electrical parameters

Frequency Range(MHz)

824-960/1710-2500

Gain(dBi)

3-7

Horizontal-3dB Beamwidth(°)

360

Vertical-3dB Beamwidth(°)

37-33/21-18

VSWR

≤1.5

Input Impedance(Ω)

50

Electrical Head Angle(°)

25~16

Polarization

V

Max Input Protection(W)

50

Connector

N-Female

Lighting Protection

DC Ground

Mechanical parameter

Antenna Dimension(mm)

φ160X900

Cover Material

PVC

Weight(kg)

4.8

Installation

Expansion bolt installation

Rated Wind Velocity (m/s)

60

Operating Temperature(°)

-40~+60

824-2500MHz Electronic Tv Antenna / LED Light Lamps Antenna Wifi Outdoor Extender

Why customer choose to work with us?
We know what customer need and quick to provide the solution.
We have large order from different clients and very close relationship with the suppliers so we provide most favorable prices.
We transfer production information efficiently and transparently to the clients.
We provide excellent after-sale service and also help customers to look for any possible product they need efficiently to save their time and build the trust while reducing the risks, we bridge the world.
It's easy to describe the above, but it's not easy to really achieve the above.
Plastic parts of the antenna and sheet metal parts are our own production, so the production capacity and quality we can accurately control.
What is beneficial for you ?
1. Give you a profession wireless solution .
2. A full quotation as your required will be offered in 24 hours .
3. Samples will be delivered within 3 days .
4. 15-designers team-workers will give you ideas for your required products.
