Ultra Thin Printed Circuit Heat Exchanger for Automotive Energy
Ultra Thin Printed Circuit Heat Exchanger for Automotive Energy
Ultra Thin Printed Circuit Heat Exchanger for Automotive Energy
Ultra Thin Printed Circuit Heat Exchanger for Automotive Energy
Specifications
Brand Name :
XHS/Customize
Model Number :
Customize
Certification :
ISO 9001, ISO 14001, IATF 16949
Place of Origin :
China
MOQ :
10
Price :
50-100USD
Payment Terms :
T/T
Supply Ability :
10000-100000PCD / week
Delivery Time :
5-10 work days
Packaging Details :
PE bags and Carton
Material :
Aluminum,alloy
Thickness :
0.5-5.0MM
Tolerance :
+/-0.01mm
Applications :
Suitable for a wide range of industries including chemical, petrochemical, and power generation
Operating Temperature Range :
-50°C to 500°C
Certifications :
ASME, PED, TUV, and ISO 9001 certified
Weight :
Up to 80% lighter than traditional heat exchangers
Description

Ultra Thin Printed Circuit Heat Exchanger for Automotive Energy


PCHE Overview
Xinhaisen Technology specializes in manufacturing high-performance etched metal plate heat exchangers through advanced chemical etching technology. Our precision-etched plates enable superior thermal transfer efficiency with optimized flow channels for various industrial applications.


PCHE Features

·Enhanced Thermal Efficiency
·Material Flexibility
·Compact Design
·Corrosion Resistant
·Custom Patterns
·Scalable Production


PCHE Specification

Parameter Specification
Material Options 316L Stainless Steel, Titanium, Nickel , Aluminum,etc.
Plate Thickness 0.5mm - 5.0mm (standard)
Tolerance ±0.01mm (high precision)
Surface Finish Ra 0.8μm (standard), Ra 0.4μm (high polish)

Ultra Thin Printed Circuit Heat Exchanger for Automotive Energy

Performance Advantages

·40% Higher Efficiency vs. conventional designs
·Uniform Flow Distribution - Precision-etched channels
·Compact & Lightweight - Ideal for space-constrained applications
·Leak-Free - No mechanical stress or heat distortion


PCHE Applications

• HVAC Systems: Chillers, heat pumps

• Industrial Processes: Chemical, petrochemical

• Power Generation: Waste heat recovery

• Marine & Offshore: Compact cooling systems

• Food & Beverage: Pasteurization systems

• Electronics Cooling: High-power devices


Quality Assurance

• Material certification (EN 10204 3.1/3.2)
• 100% dimensional inspection
• Pressure testing capabilities
• Leak testing (helium mass spectrometry)
• ISO 9001:2015 certified production

Ultra Thin Printed Circuit Heat Exchanger for Automotive Energy
