Precision Encoder Discs Photo Etched Stainless Steel Optical Code Discs
Precision Encoder Discs Photo Etched Stainless Steel Optical Code Discs
Precision Encoder Discs Photo Etched Stainless Steel Optical Code Discs
Precision Encoder Discs Photo Etched Stainless Steel Optical Code Discs
Specifications
MOQ :
10
Delivery Time :
5-10 work days
OEM :
available
Application :
Servo / CNC / Robotics
Model Number :
Customize
Hole Diameter :
Custom
Payment Terms :
T/T
Resolution :
Custom PPR
Price :
50-100USD
Materials :
Stainless steel or customized
Supply Ability :
10000-100000PCD / week
Tolerance :
±0.01mm
Brand Name :
XHS/Customize
Product Name :
Etched Encoder Discs
Certification :
ISO 9001, ISO 14001, IATF 16949
Etching Method :
Photo Chemical Etching
Place of Origin :
Customize
Shape :
As client's request
Packaging Details :
PE bags and Carton
Description

Precision Encoder Discs Photo Etched Stainless Steel Optical Code Discs


Precision Etched Encoder Discs Manufacturer

Xinhaisen manufactures high precision photo etched encoder discs for optical rotary encoders used in motion control, industrial automation, robotics, aerospace, medical equipment, semiconductor equipment and precision positioning systems.

Unlike stamping or laser cutting, chemical etching produces burr-free and stress-free encoder discs without affecting material properties, ensuring reliable optical signal transmission and long-term performance.



Encoder Discs Overview
High-precision etched encoder discs for optical encoders, rotary encoders, and motion control systems. Custom stainless steel encoder wheels with burr-free edges and excellent dimensional accuracy..

Encoder Discs Features
1.Ultra-High Precision: Capable of producing extremely fine lines and micro-holes.
2.Burr-Free & Stress-Free: The etching process eliminates mechanical stresses and burrs, ensuring smooth edges and accurate performance.
3.No Material Hardness Change: Unlike stamping or laser cutting, etching does not affect the base metal's temper or magnetic properties.
4.Rapid Prototyping & Production: Fast turnaround from design to mass production.
5.Material Versatility: Can be etched from various alloys.
  • High precision optical encoder patterns
  • Burr-free photo chemical machining
  • Ultra fine line widths
  • No tooling stress or deformation
  • Excellent repeatability


Encoder Discs SpecificationsPhoto Etched Encoder Disc

Product Name Photo Etched Encoder Disc
Material Stainless Steel 304 / 316 / Nickel
Thickness 0.02-1.0 mm
Tolerance ±0.005 mm
Min Line Width 0.01 mm
Application Rotary Encoder
Process Photo Chemical Etching
OEM Available


Precision Encoder Discs Photo Etched Stainless Steel Optical Code Discs

Precision Encoder Discs Photo Etched Stainless Steel Optical Code Discs

Applications

Optical encoder discs are commonly used in:

  • Robotics
  • CNC Machines
  • Medical Equipment
  • Semiconductor Equipment
  • Aerospace Instruments
  • Precision Measuring Devices
  • Automation Sensors
  • Optical Rotary Encoders
  • Servo Motors
  • Motion Control Systems
  • Industrial Automation

Why Choose Xinhaisen?

Photo chemical etching is the preferred manufacturing method for precision encoder discs because it creates complex optical patterns without mechanical stress or burrs. It enables extremely fine geometries, excellent repeatability, and cost-effective production from prototypes to high-volume manufacturing.

Xinhaisen provides custom etched encoder discs tailored to customer drawings, ensuring consistent quality and reliable performance for demanding encoder applications.
