eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
eva foam and shoe sponge rubber sheet splitting cutter machine
Specifications
Place of Origin :
China
Brand Name :
Mixer
Type :
Bandknife Splitting Machine
Condition :
New
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
More than 5 years
Core Components :
PLC, Engine, Bearing, Motor, Gear
Voltage :
380V,220V,480V
Dimension(L*W*H) :
3900x1150x2100mm
Warranty :
1 Year
Key Selling Points :
Multifunctional
Power (kW) :
45 kW
Weight (KG) :
6000 KG
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Splitting machine :
EVA/PE foam sheet splitting machine
Slicing Machine :
Rubber Cork,CR,EPDM foam sheet
Power(W) :
11KW
Weight :
3200
After-sales Service Provided :
Field installation, commissioning and training
After Warranty Service :
Video technical support
Marketing Type :
New Product 2020
Packaging Details :
film wrap into container
Port :
Shanghai
Supply Ability :
60DAYS
Price :
$16,500.00 - $20,000.00/sets
MOQ :
1set
Delivery Time :
60days
Payment Terms :
T/T
Description

Product Description

eva foam and styrofoam sponge sheet cutter

Application:
The machine is applied to splitting the foamed rubber cork, foamed EVA, PE, etc. at a high speed and precision.
Features:
1. Cutter with holder plate is spray welded with tingsten, featuring abrasion resistant, non-deformation and it doesn’t clamp the cutter.
2. The speed is controlled through a powerful mechanic gearbox, featuring speedy change without reducing the power, lower failure rate.
3. The splitting thickness is set by the digital switch, featuring high precision.
4. The splitting thickness is set by the digital switch, featuring high precision. The main components, like motor, gear box, drive bearing, electric elements, are all made from Taiwan or Japan brand, with reliable and stable performance, making sure the machine with longer service life.
Specification

Item

Contents

Data

1

Slicing width

1800 mm

2

Slicing Thickness

0.3-120 mm

3

Slicing Hardness

10°-80°

4

Slicing Speed

10M-40 M/min

5

Slicing Precision

±0.05 m/m Or ±5%

6

Drive Power

11KW

7

Band knife Dimension

1.0×90×8100m/m

8

Machine Dimension

3900×1150×2100 mm

9

Equipment Weight

3200KG

Packaging & Shipping

eva foam and shoe sponge rubber sheet splitting cutter machineeva foam and shoe sponge rubber sheet splitting cutter machineeva foam and shoe sponge rubber sheet splitting cutter machineeva foam and shoe sponge rubber sheet splitting cutter machine
