Quenched Tempered EN 1.4935 X20CrMoWV12-1 Solid Stainless Steel Rectangular Bar
Quenched Tempered EN 1.4935 X20CrMoWV12-1 Solid Stainless Steel Rectangular Bar
Quenched Tempered EN 1.4935 X20CrMoWV12-1 Solid Stainless Steel Rectangular Bar
Quenched Tempered EN 1.4935 X20CrMoWV12-1 Solid Stainless Steel Rectangular Bar
Specifications
Brand Name :
UST
Model Number :
EN 1.4935 (X20CrMoWV12-1)
Certification :
ISO
Place of Origin :
CHINA
MOQ :
MOQ5tons
Price :
$2000-3000/ton
Payment Terms :
CIF CFR FOB Ex-Work
Supply Ability :
800 tons per month
Delivery Time :
4-6 weeks
Packaging Details :
seaworthy package
condition :
Quenched and tempered treatment
En :
X20CrMoWV12-1
Original :
China
Standard :
EN
Product Name :
EN 1.4935 Stainless Steel
Description

EN 1.4935 (X20CrMoWV12-1) Stainless Steel China supplier

EN 1.4935 Stainless Steel Specifications:

Grade : X20CrMoWV12-1
Number: 1.4935
Classification: Alloy special martensitic creep-resisting steel
Density: 7.7 g/cm
Standard: EN 10302: 2008 Creep resisting steels, nickel and cobalt alloys
EN 10088-1: 2005 Stainless steels. List of stainless steels
Equivalent grades: No information


Chemical composition % of steel X20CrMoWV12-1 (1.4935): EN 10302-2008

C Si Mn Ni P S Cr Mo W V
0.17 - 0.24 0.1 - 0.5 0.3 - 0.8 0.3 - 0.8 max 0.025 max 0.015 11 - 12.5 0.8 - 1.2 0.4 - 0.6 0.2 - 0.35

Mechanical properties of steel X20CrMoWV12-1 (1.4935)

Rm - Tensile strength (MPa) (+QT700) 700-850
Rm - Tensile strength (MPa) (+QT800) 800-950
Rp0.2 0.2% proof strength (MPa) (+QT700) 500
Rp0.2 0.2% proof strength (MPa) (+QT800) 600
A - Min. elongation at fracture (%) (+QT700) 15-16
A - Min. elongation at fracture (%) (+QT800) 14

EN 1.4935 Stainless Steel Heat treatment conditions:
+A Soft annealed
+AC Annealed to achieve spheroidization of the carbides
+AR As rolled
+AT Solution annealed
+C Cold drawn / hard
+CR Cold rolled
+FP Treated to ferrite-pearlite structure and hardness range
+I Isothermal annealing
+LC Cold drawn / soft
+M Thermo mechanical rolling
+N Normalized
+NT Normalized and tempered
+P Precipitation hardened
+PE Peeled
+QA Air quenched and tempered
+QL Liquid quenched and tempered
+QT Quenched and tempered
+S Treated to improve shearability
+SH As rolled and turned
+SR Cold drawn and stress relieved
+T Tempered
+TH Treated to hardness range
+WW Warm worked
+U Untreated

MECHANICAL PROPERTIES UNDER ROOM TEMPERATURE
  • Condition: Quenched and tempered treatment
  • Tensile strength, σb/MPa: 780 ~ 930
  • yield strength, σs ≥/MPa: 590
  • Elongation, δ5 ≥(％): 14.0
  • Hardness: HRC 25 ~ 30
  • Non-scale temperature in Air: 600℃
