Customizable Hydraulic Cargo Lift | 500kg–5000kg Vertical Elevator
Customizable Hydraulic Cargo Lift | 500kg–5000kg Vertical Elevator
Customizable Hydraulic Cargo Lift | 500kg–5000kg Vertical Elevator
Customizable Hydraulic Cargo Lift | 500kg–5000kg Vertical Elevator
Specifications
Brand Name :
HAOXIANG BRAND
Model Number :
DSL2-8
Certification :
CE/ISO
Place of Origin :
GUANGDONG,CHINA
MOQ :
1 unit
Price :
USD2300- USD6980 / UNIT
Payment Terms :
T/T
Supply Ability :
1500 UNITS PER YEAR
Delivery Time :
7-15 working days
Packaging Details :
Naked packaging
Product Name :
Vertical Goods Lift
Height :
8 Meters
Load capacity :
2tons
Installation :
Easy installation, video guidance provided
Function :
Overload Protection
Table Size :
1600*1500mm
Driven Type :
Hydraulic
Country Of Origin :
Made in China
Description
Customizable Hydraulic Cargo Lift | 500kg–5000kg Vertical Elevator
Product Specifications
Product nameHydraulic Vertical Goods Lift
InstallationEasy installation, video guidance provided
Table Size1600*1500mm
FunctionOverload Protection
Driven TypeHydraulic
Height8 Meters
Load capacity2tons
What is the Hydraulic Guide Rail Lift?

A freight elevator primarily assists in the vertical movement of goods through multiple levels. It is widely used in industrial factories for handling production materials, warehouses for storing and shifting stock, shopping centers for product and shelf transport, and hotels for kitchen and housekeeping needs.

Key Benefits
  • Strengthened Hydraulic Core: Provides consistent, heavy-duty lifting with smooth operation.
  • Extreme Capacity: Built for handling oversized goods and concentrated weight loads.
  • Flexible Deployment: Can be positioned in warehouses, workshops, or open environments.
  • Multi-Layer Safety: Features overload prevention, emergency stops, and protective gates.
  • Compact Vertical Layout: Small footprint with maximum lift height utilization.
Technical Specifications

Specifications, sizes and colors can be customized according to customer requirements.

ModelRated load (kg)Lifting stroke (mm)Lowering height (mm)Table size (mm)Lifting timeMotor power (kw)
DSL1-3100030001002000×18006m/min3
DSL2-4200040001502000×18006m/min4
DSL2-102000100002003000×35006m/min4
DSL3-5300050001503000×18006m/min5.5
DSL3-8300080001502000×17006m/min5.5
DSL4-5400050002503000×40006m/min7.5
DSL4-104000100001505000×30006m/min7.5
DSL5-6500060004005800×30006m/min11
Product Gallery
Customizable Hydraulic Cargo Lift | 500kg–5000kg Vertical Elevator Customizable Hydraulic Cargo Lift | 500kg–5000kg Vertical Elevator Customizable Hydraulic Cargo Lift | 500kg–5000kg Vertical Elevator
About Our Company

Situated in Xiaolan Township, Zhongshan City, Guangdong Haoxiang Machinery Manufacturing Co., Ltd. operates as a certified high-technology manufacturing enterprise specializing in hydraulic logistics solutions. With 30 million RMB registered capital and annual production value exceeding 100 million RMB, our company maintains a 21,500-square-meter modern production facility.
Committed to developing ultra-safe, high-efficiency lifting systems, we prioritize creating innovative hydraulic lifting platforms that deliver reliable performance across logistics, warehousing, and industrial applications.
Equipped with advanced manufacturing technologies and rigorous quality control systems, we have established ourselves as an industry benchmark recognized for precision engineering and operational excellence. Our extensive service network includes 45 professional installation teams supporting over 40,000 client enterprises nationwide.
We guarantee rapid-response services with 2-hour on-site support available in the Pearl River Delta region and 24-hour emergency response coverage across China, ensuring complete peace of mind for all equipment users.
